Clamcleat CL203/S2 Junior Cleats with Bottom Roller for 3–6 mm Rope

ID 1394976

$ 7.28

1-2 weeks delivery time

Color:

Black
White

Clamcleat CL203/S2 Junior cleats are compact nylon rope cleats with an integrated bottom roller for 3–6 mm (1/8–1/4") rope. The roller allows the line to enter the cleat from below, providing a smooth and controlled rope path for specific mounting orientations. Suitable for lower-load applications, the cleats can also be raised using the CL824 Riser Pad or rigged directly onto 4–5 mm rope. Available in black CL203/S2 and white CL203W/S2 versions.

Description
Ask a Question

Clamcleat CL203/S2 Junior Cleats with Bottom Roller for 3–6 mm Rope, Black or White Nylon

Clamcleat CL203/S2 is a compact Junior nylon cleat fitted with an integrated bottom roller and designed for ropes from 3 to 6 mm (1/8–1/4").

The bottom roller allows the rope to enter the cleat from below, creating a smooth and controlled rope path where the line approaches from underneath the mounting surface.

The CL203/S2 series is intended primarily for lower-load applications. Where additional mounting height is required, the cleat can be installed with the CL824 Riser Pad. It can also be rigged directly onto 4–5 mm (5/32–3/16") rope.

Two colour variants are available: CL203/S2 in black nylon and CL203W/S2 in white nylon.

Product Features

Brand: Clamcleat
Series: Junior
Models: CL203/S2 and CL203W/S2
Product type: Nylon rope cleat with bottom roller
Material: Nylon
Rope diameter: 3–6 mm (1/8–1/4")
Integrated bottom roller
Allows rope entry from below
Provides a smooth and controlled rope path
Designed for lower-load applications
Compatible with CL824 Riser Pad
Can be rigged directly onto 4–5 mm rope
Available in black or white

Technical Specifications

Parameter	Specification
Rope Diameter	3–6 mm (1/8–1/4")
Direct Rope Rigging	4–5 mm (5/32–3/16")
Material	Nylon
Hole Centres	66 mm
Length	82 mm
Width	18 mm
Height	23 mm
Bolt Size	M4
Screw Size	4.2 mm / No. 8
Weight	Approx. 17 g
Rope Entry	From below via bottom roller
Compatible Riser Pad	CL824

Available Variants

Model	Colour	Rope Diameter
CL203/S2	Black	3–6 mm
CL203W/S2	White	3–6 mm
