The Barton N00511 is a Size 0 triple fixed eye block with becket and integrated cam cleat, featuring three 20 mm plain bearing sheaves for ropes up to 6 mm. Weighing 104 g, it provides reliable load handling with a working load of 275 kg and break load of 550 kg, making it ideal for compact multi-purchase systems with built-in line control.
- Description
- Ask a Question
-
Barton N00511 - Triple Fixed Eye Block with Becket and Cam Size 0 20mm – Plain Bearing, 3x Ø20mm Sheaves, Max Rope 6mm
The Barton N00511 Triple Fixed Eye Block with Becket and Cam is part of the Size 0 (20 mm) range, featuring three plain bearing sheaves and an integrated cam cleat for secure line control. The becket allows rope termination, making it suitable for compact multi-purchase systems.
The fixed eye attachment ensures stable mounting, while the plain bearing system is optimized for high static loads and controlled adjustment. The integrated cam cleat enables quick locking and release of the line, making this block ideal for dinghies, racing boats, and small craft where efficient control is required.
Key Features
- Triple sheave block with integrated becket and cam cleat
- Plain bearing system for strength and durability under load
- Cam cleat for fast and secure line handling
- Fixed eye for stable mounting
- Compact and robust construction – 104 g
Technical Specifications
Part Number N00511 Block Type Triple Fixed Eye + Becket + Cam Size Size 0 (20 mm) Sheave Diameter 3 × 20 mm x 8 mm (25/32"" x 5/16"") Bearing Type Plain Bearing Number of Sheaves Triple Max Rope Diameter 6 mm (1/4"") Safe Working Load (SWL) 275 kg (606 lbs) Break Load 550 kg (1210 lbs) Weight 104 g Dimensions 66 × 52 × 47 mm
Applications
- Multi-purchase systems with integrated line control
- Downhauls and kicking straps
- Control and trimming systems
- Dinghies and performance sailing boats
The Barton Size 0 plain bearing triple blocks with becket and cam are engineered for efficient control and reliable performance, combining load handling and line management in a compact system.
-
