Barton N02150 - Single Upright Block Size 2 35mm – Plain Bearing, Ø35mm Sheave, Max Rope 8mm

ID 1360668

$ 114.40

1-2 weeks delivery time

- +

Add to cart

The Barton N02150 is a Size 2 single upright block with a 35 mm plain bearing sheave, designed for ropes up to 8 mm. Weighing 78 g, it provides reliable load handling with a working load of 370 kg and break load of 740 kg, making it ideal for fixed-position line guidance on deck, mast, or boom.

Description
Ask a Question

Barton N02150 - Single Upright Block Size 2 35mm – Plain Bearing, Ø35mm Sheave, Max Rope 8mm

The Barton N02150 Single Upright Block is part of the Size 2 (35 mm) range, featuring a plain bearing sheave and an internal stainless steel frame for enhanced strength and durability. The upright configuration is designed for fixed mounting to control line direction in deck and rigging setups.

The plain bearing system is optimized for high load capacity and controlled line movement, ensuring dependable performance under load. This block is particularly suitable for installations where a fixed lead is required, such as on the deck, mast, or boom.

Key Features

Single sheave upright block for fixed mounting
Internal stainless steel frame for increased strength and durability
Plain bearing system for high load applications
Designed for directing lines from a fixed position
Robust construction – 78 g

Technical Specifications

Part Number	N02150
Block Type	Single Upright
Size	Size 2 (35 mm)
Sheave Diameter	35 mm x 11 mm (1 3/8"" x 15/32"")
Bearing Type	Plain Bearing
Number of Sheaves	Single
Max Rope Diameter	8 mm (5/16"")
Safe Working Load (SWL)	370 kg (815 lbs)
Break Load	740 kg (1630 lbs)
Weight	78 g
Dimensions	62 × 49 × 51 mm

Applications

Deck-mounted line guidance
Mast and boom installations
Fixed-position control systems
Dinghies, dayboats, and yachts

The Barton Size 2 upright blocks are engineered for strength, durability, and precise line control, delivering reliable performance in fixed rigging applications.
