Tecnoseal Yamaha Outboard Anode Kit 60–90 HP

Tecnoseal Yamaha Outboard Anode Kit 60–90 HP – Zinc, Aluminium or Magnesium

The Tecnoseal KITYAMAHA60-90 series consists of sacrificial anode kits designed for Yamaha 60–90 HP outboard motors. Each kit contains two replacement anodes manufactured from the same sacrificial material, intended to help protect compatible Yamaha outboard components against galvanic corrosion. Mounting hardware is not included.

Each kit includes one Tecnoseal 01104 series anode and one Tecnoseal 01115 series anode. During service, the sacrificial anode material corrodes preferentially, helping reduce galvanic corrosion of protected metallic outboard components. All three kit versions contain the same component types in their respective materials.

Three versions are available: zinc (Tecnoseal KITYAMAHA60-90, Osculati 43.354.00), aluminium (Tecnoseal KITYAMAHA60-90-AL, Osculati 43.354.01) and magnesium (Tecnoseal KITYAMAHA60-90-MG). According to the Tecnoseal catalogue, the zinc kit weighs 1.05 kg (2.31 lbs), the aluminium kit weighs 0.49 kg (1.08 lbs) and the magnesium kit weighs 0.36 kg (0.79 lbs).

Technical Specifications

Available Kit Versions and Cross-References

Kit Contents

Individual Kit Components

• Zinc Kit – Tecnoseal KITYAMAHA60-90 / Osculati 43.354.00:
  • 1 × Tecnoseal 01104 zinc anode
  • 1 × Tecnoseal 01115 zinc anode
  • Total: 2 zinc anodes
• Aluminium Kit – Tecnoseal KITYAMAHA60-90-AL / Osculati 43.354.01:
  • 1 × Tecnoseal 01104AL aluminium anode
  • 1 × Tecnoseal 01115AL aluminium anode
  • Total: 2 aluminium anodes
• Magnesium Kit – Tecnoseal KITYAMAHA60-90-MG:
  • 1 × Tecnoseal 01104MG magnesium anode
  • 1 × Tecnoseal 01115MG magnesium anode
  • Total: 2 magnesium anodes

Packaging Options

The Tecnoseal catalogue lists the following packaging formats for these anode kits:

• Branded box
• Blister pack for hanging display
• Polybag
• Skin pack for hanging display

The packaging format supplied with an individual order should be confirmed separately.

Compatibility and Cross-References

• Compatible Manufacturer: Yamaha
• Outboard Power Range: 60–90 HP
• Zinc Kit: Tecnoseal KITYAMAHA60-90 / Osculati 43.354.00
• Aluminium Kit: Tecnoseal KITYAMAHA60-90-AL / Osculati 43.354.01
• Magnesium Kit: Tecnoseal KITYAMAHA60-90-MG
• Included Component Series: Tecnoseal 01104 and 01115

Key Features

• Designed for compatible Yamaha 60–90 HP outboard motors.
• Two-piece sacrificial anode kit.
• Includes one Tecnoseal 01104 series anode.
• Includes one Tecnoseal 01115 series anode.
• Available in zinc, aluminium and magnesium versions.
• Zinc kit: 1.05 kg, Osculati 43.354.00.
• Aluminium kit: 0.49 kg, Osculati 43.354.01.
• Magnesium kit: 0.36 kg.
• Mounting hardware is not included.
• Provides sacrificial corrosion protection for compatible outboard components.

Compatibility Note: Before ordering, verify the Yamaha outboard model and individual anode part numbers included in the kit. The stated 60–90 HP range does not establish compatibility with every Yamaha outboard within that range. Select the appropriate sacrificial anode material according to Yamaha's recommendations and operating water conditions. Mounting hardware is not included and must be supplied separately if required.
