ID
1317179
$ 235.68
1-2 weeks delivery time
-
+
The TMC-06601 Pump 24 Volt 4.60M/8,7M4 is a robust and oil-resistant submersible centrifugal pump designed for inland shipping and water sports. It features an open plastic impeller, brush motor, and stainless steel pump shaft, pumps down to 10 mm water level, and delivers a maximum discharge head of 4.7 meters with a free flow capacity of 7,500 liters per hour at 24 V DC.
- Description
- Ask a Question
-
TMC-06601 Pump 24 Volt 4.60M/8,7M4
The white and blue 24 Volt version of the 06601 pump is similarly robust and oil resistant, designed for use in inland shipping and water sports with a completely submersible centrifugal design.
- Type: 06601
- Impeller: open plastic impeller
- Motor: brush motor without fuse inbuilt
- Shaft seal: ceramic on carbon mechanical seal with lip seal
- Materials: plastic impeller housing, plastic motor housing, stainless steel pump shaft
- Pumps down to 10 mm water level
- Connection: 1.1/4" hose connection
- Dimensions: diameter 132/166 mm, height 195 mm
- Weight: 0.9 kg
- Electrical: 24 V, 8.0 A amperage
- Cable: 1 metre without plug
- Product code: 91.05.524
- Pipe diameter pressure: 1.1/4"
- Particle size: 2 mm max
- Max discharge head: 4.7 m
- Voltage: 24 V DC
- Free flow capacity: 7500 L/Hour
- No ATEX certification, no separate float switch
-
