ID
1317184
$ 4,381.10
1-2 weeks delivery time
-
+
The Victor Pumps S60G31T 4,0KW is a high-capacity deck wash and bilge pump for commercial shipping, featuring a self-priming centrifugal pump with an open impeller that can handle particles up to 17 mm. It delivers impressive flow rates, such as 42,500 litres/hour at 10 meters head, and is built for durability with a weight of 71 kg and flange connections for 2" pipes.
- Description
- Ask a Question
-
Victor Pumps S60G31T 4,0KW
Designed for commercial shipping, this deck wash and bilge pump delivers high capacity and durability for handling liquids with coarse particles.
- Type: S
- Colour: blue
- Pump type: self-priming centrifugal pump
- Impeller type: open impeller
- Motor type: short circuit motor
- Fuse: NOT inbuilt
- Insulation class: IP55
- Shaft seal: SiC on ceramic mechanical seal with Viton, in oil bath
- Material impeller: cast steel
- Material wearing plate: cast steel
- Material pump housing: cast iron
- Material pump shaft: stainless steel
- Liquids handled: clean and contaminated liquids with coarser particles such as water, sea water, gas oil
- Performance at head:
- 10 m: 42,500 litres/hour
- 15 m: 37,500 litres/hour
- 20 m: 30,000 litres/hour
- 25 m: 23,000 litres/hour
- 30 m: 13,000 litres/hour
- Connections: 2" internal thread
- Dimensions (L×W×H): 569 × 280 × 350 mm
- Weight: 71 kg
- Amperage: 8.4 A
- Shaft power: 4.0 kW, 5.3 hp, 2900 rpm
- Product code: 92.09.060
- Suction head: 8.0 m
- Pipe diameter pressure: 2"
- Pipe diameter suction: 2"
- Pump type: Dry set-up pump, self-priming
- Medium: Water and water with coarse components
- Max particle size: 17 mm
- Max discharge head: 32.0 m
- Voltage: 400 V
- Current: AC
- Frequency: 50 Hz
- Protection class: IP68
- ATEX: No
- Separate float switch: Not included
- Free flow: 45,000 L/hour
- Capacity at 5 m head: 45,000 L/hour
-
