Simrad 000-15405-001 - NSS9 EVO3S Multifunction Display

ID 1341780

$ 4,363.99

1-2 weeks delivery time

- +

Add to cart

The Simrad NSS9 evo3S is a high-end 7" chartplotter with a six-core iMX 8 processor and SolarMAX™ IPS display, offering split screens, multiple pages, 3D views, and integrated sonar including Dual CHIRP, StructureScan 3D, SideScan, ForwardScan, and Active Imaging™. It connects via NMEA 2000®, Ethernet, Wi-Fi, Bluetooth, and HDMI, and operates on 12/24 V DC with 23 W consumption, dimensions 287 x 166.3 x 112.5 mm, and weighs 1.4 kg.

Description
Ask a Question

Simrad 000-15405-001 - NSS9 EVO3S Multifunction Display

The Simrad NSS9 evo3S Multifunction Display is a high-end chartplotter designed to deliver an ultra-smooth navigation experience, even in demanding marine conditions. Powered by an ultra-fast six-core iMX 8 processor and equipped with a SolarMAX™ IPS display, it offers outstanding speed, clarity, and seamless integration with onboard systems.

Key Features

Ultra-fast six-core iMX 8 processor for instant response and smooth multitasking
7" SolarMAX™ IPS display, ultra-bright and readable with polarized sunglasses
Touchscreen combined with integrated keypad for full control in all conditions
Wide chart compatibility including C-MAP®, Navionics®, CMOR, and NV Digital
Advanced integrated sonar: Dual CHIRP, StructureScan 3D, SideScan, ForwardScan, and Active Imaging™
Support for external sonar modules for extended capabilities
Extensive connectivity: NMEA 2000®, Ethernet, Wi‑Fi, Bluetooth, and HDMI
Highly customizable interface with split screens, multiple pages, and 3D views
Simple software updates via Wi‑Fi or USB flash drive

Technical Data

Power Supply	DC
Operating Voltage	12 / 24 V
Power Consumption	23 W
Frequency	40–250 / 455–800 kHz
Dimensions	287 x 166.3 mm
Depth	112.5 mm
Weight	1.4 kg
Ingress Protection	IPX6 & IPX7
Model	NSS 9 Evo3S

Brand Simrad | Article 000-15405-001
