BEP Marine Circuit Breaker HD 120A Switchable Reset Panel Mount (Bulk) Packaged Per 10

SKU: EX 185120P-01-1

€ 75,76

1-2 weeks delivery time
Price incl. 19% VAT

- +

Add to cart

The BEP Marine Circuit Breaker is a heavy-duty, single pole thermal breaker ideal for auxiliary and accessory circuits in trucks, buses, RVs, and marine applications, including battery chargers and DC audio systems. Sealed for engine compartments and bilge areas, it features durable materials like tin plated copper studs and stainless steel locking nuts. With a rating of 30-150A and an interrupt capacity of 3000A, it operates in extreme temperatures and offers a visible reset mechanism, complying with various safety standards.

Description
Ask a Question

BEP Marine Circuit Breaker HD 120A Switchable Reset Panel Mount (Bulk) Packaged Per 10

The BEP Marine Circuit Breaker is designed for heavy-duty applications, making it an excellent choice for various vehicles and marine environments.
- Product Number: 185120P-01-1
- Heavy-duty single pole thermal type breakers for auxiliary and accessory circuits.
- Suitable for trucks, buses, RVs, and marine applications, including battery chargers and DC audio systems.
- Series 184 and 185 are sealed for engine compartment and bilge area applications.
- Stud insulators included on covered units with F (Surface Mount) bases.
- Tin plated copper studs, brass rivets, and stainless steel locking nuts for durability.
- Ratings: 30-150A; 30V DC, 3000A interrupt capacity.
- Operating Temperature: -25°F (-32°C) to 180°F (82°C).
- Storage Temperature: -30°F (-34°C) to 300°F (149°C).
- Housing: Thermoset plastic; UL rated 94VO; 311°F (155°C).
- Mounting options: Panel or surface.
- Terminal Stud Torque: 50 in-lb (5.6Nm) max.
- Features a unique reset mechanism for visible indication of tripped condition.
- Ingress Protection Rating: IP67.
- Approved under SAEJ1625, J1171, and UL1500 (Ignition protected) specifications.
