BEP Marine Circuit Breaker HD 100A Switchable Reset Panel Mount (Bulk) Packaged Per 10

SKU: EX 185100P-01-1

€ 75,76

1-2 weeks delivery time
Price incl. 19% VAT

- +

Add to cart

The BEP Marine Circuit Breaker HD 100A is a heavy-duty single pole thermal breaker designed for auxiliary and accessory circuits in trucks, buses, RVs, and marine applications. It features a sealed design for engine compartments and bilge areas, with materials including tin-plated copper studs and stainless steel locking nuts. Rated for 30-150A and capable of interrupting up to 3000A, it operates in temperatures from -25°F to 180°F. The circuit breaker includes a unique reset mechanism that visibly indicates when it has tripped and complies with multiple safety standards.

Description
Ask a Question

BEP Marine Circuit Breaker HD 100A Switchable Reset Panel Mount (Bulk) Packaged Per 10

Introducing the BEP Marine Circuit Breaker, designed for heavy-duty applications in various vehicles and marine environments. This reliable switchable reset panel mount ensures safety and efficiency across auxiliary and accessory circuits.
- Product Number: 185100P-01-1
- Type: Heavy-duty single pole thermal circuit breaker
- Ideal for: Trucks, buses, RVs, marine applications, battery chargers, and DC audio systems
- Sealed for: Engine compartment and bilge area applications
- Stud Insulators: Provided on covered units with F (Surface Mount) bases
- Materials: Tin plated copper studs, brass rivets, stainless steel locking nuts
- Ratings: 30-150A; 30V DC, 3000A interrupt capacity
- Operating Temperature: -25°F (-32°C) to 180°F (82°C)
- Storage Temperature: -30°F (-34°C) to 300°F (149°C)
- Housing: Thermoset plastic; UL rated 94VO; 311°F (155°C)
- Mounting: Panel or surface
- Terminal Stud Torque: 50 in-lb (5.6Nm) max
- Indicator: Unique reset mechanism provides visible indication of tripped condition
- Ingress Protection Rating: IP67
- Approvals: Complies with SAEJ1625, J1171, and UL1500 (Ignition protected) specifications
