ID
1317211
$ 65.57
1-2 weeks delivery time
-
+
The Wika Bourdon Tube Pressure Gauge with brass measuring system and 63 mm stainless steel case includes a bottom connection with back flange and measures pressure from -1 to 0 bar, designed for accurate monitoring of non-aggressive gases and liquids.
- Description
- Ask a Question
-
Wika Bourdon Tube Pressure Gauge Brass, Case Ø 63mm Bottom Connection With Back Flange 1/4'' -1+0 Bar
Engineered for accurate monitoring of non-aggressive gases and liquids, this gauge includes a brass measuring system and a back flange for enhanced mounting options. It adheres to accuracy class 1.6 in line with DIN 16005 standards.
- Case: Ø 63 mm, bottom connection with back flange
- Case material: Stainless steel 304
- Measuring system: Brass
- Dial: White with black lettering
- Pointer: Black
- Window: Plastic
- Case fill: Glycerine
- Dimensions: As per DIN16063 or 16064
- Product code: 40.25.301
- Connection: 1/4" BSP bottom connection with back flange
- Measuring range: -1 + 0 bar
-
