ID
1317210
$ 59.60
1-2 weeks delivery time
-
+
This Wika Bourdon Tube Pressure Gauge has a brass measuring system, a 63 mm stainless steel case with bottom connection and back flange, and measures pressure from 0 to 16 bar, certified for precise measurement.
- Description
- Ask a Question
-
Wika Bourdon Tube Pressure Gauge Brass, Case Ø 63mm Bottom Connection With Back Flange 1/4'' 0-16 Bar
Built for precise measurement of non-aggressive gases and liquids, this gauge features a brass measuring system and a back flange for easy installation in cooling, pneumatic, and hydraulic systems. It is certified for accuracy class 1.6 according to DIN 16005.
- Case: Ø 63 mm, bottom connection with back flange
- Case material: Stainless steel 304
- Measuring system: Brass
- Dial: White with black lettering
- Pointer: Black
- Window: Plastic
- Case fill: Glycerine
- Dimensions: As per DIN16063 or 16064
- Product code: 40.25.203
- Connection: 1/4" BSP bottom connection with back flange
- Measuring range: 0 - 16 bar
-
