ID
1317212
$ 65.57
1-2 weeks delivery time
-
+
The Wika Bourdon Tube Pressure Gauge with a brass measuring system and back flange features a 63 mm stainless steel case and a 1/4" BSP bottom connection, measuring pressure from -1 to +0.6 bar. It is suitable for non-aggressive gases and liquids in cooling, pneumatic, and hydraulic applications, delivering precision with accuracy class 1.6 according to DIN 16005.
- Description
- Ask a Question
-
Wika Bourdon Tube Pressure Gauge Brass, Case Ø 63mm Bottom Connection With Back Flange 1/4'' -1+0.6 Bar
Suitable for use with non-aggressive gases and liquids in cooling, pneumatic, and hydraulic applications, this pressure gauge features a brass measuring system and back flange. It delivers precision with accuracy class 1.6 according to DIN 16005.
- Case: Ø 63 mm, bottom connection with back flange
- Case material: Stainless steel 304
- Measuring system: Brass
- Dial: White with black lettering
- Pointer: Black
- Window: Plastic
- Case fill: Glycerine
- Dimensions: As per DIN16063 or 16064
- Product code: 40.25.302
- Connection: 1/4" BSP bottom connection with back flange
- Measuring range: -1 + 0.6 bar
-
