ID
1317216
$ 163.92
1-2 weeks delivery time
-
+
The Wika Bourdon Tube Pressure Gauge features a 316Ti stainless steel measuring system and a 63 mm stainless steel case with a 1/4" BSP bottom connection, measuring pressure from 0 to 16 bar. It is well-suited for non-aggressive gases and liquids in various industrial applications, maintaining accuracy class 1.6.
- Description
- Ask a Question
-
Wika Bourdon Tube Pressure Gauge Stainless Steel, Case Ø 63mm Bottom Connection 1/4'' 0-16 Bar
Well-suited for the measurement of non-aggressive gases and liquids, this gauge serves the pneumatics, hydraulics, shipping, chemical, and food industries. It incorporates a 316Ti stainless steel measuring system and maintains accuracy class 1.6 according to DIN 16005 requirements.
- Case: Ø 63 mm, bottom connection
- Case material: Stainless steel 304
- Measuring system: 316Ti stainless steel
- Dial: White with black lettering
- Pointer: Black
- Window: Safety glass/polycarbonate
- Case fill: Glycerine
- Dimensions: As per DIN16064
- Product code: 40.26.004
- Connection: 1/4" BSP bottom connection
- Measuring range: 0 - 16 bar
-
