Osculati A2 AISI 304 Stainless Steel Hex Head Wood Screws DIN 571 / UNI 704, Ø6–10 mm

ID 1403497

$ 17.28

1-2 weeks delivery time

Diameter, mm:

Length, mm:

Item:

10 pcs
25 pcs

Osculati DIN 571 / UNI 704 hex head wood screws are manufactured from A2 (AISI 304) stainless steel and feature an external hexagonal head, a pointed tip and a partially threaded shaft. Designed for fastening into suitable timber and wood-based materials, these screws can be tightened using a matching wrench or socket. Their AISI 304 stainless steel construction provides corrosion resistance for general woodworking, outdoor installations and appropriate marine applications. The range includes 16 dimensional configurations in 6, 8 and 10 mm diameters, with lengths from 30 to 100 mm. Each variant is supplied in a cardboard box containing 10 or 25 screws, depending on the selected size.

Description
Ask a Question

Osculati A2 AISI 304 Stainless Steel Hex Head Wood Screws DIN 571 / UNI 704

Osculati hexagon head wood screws are manufactured from A2 (AISI 304) stainless steel and are listed according to DIN 571 / UNI 704. These fasteners feature an external hexagonal head, a partially threaded shaft and a pointed tip for installation into suitable timber and wood-based materials.

The hexagonal head allows the screw to be tightened or removed using a matching wrench or socket. Its flat bearing surface sits against the mounting component, while the pointed threaded section engages with the wood to provide a mechanical fastening connection.

According to the catalogue illustration, the screws feature a smooth shank section beneath the head and a threaded section towards the pointed end. This partially threaded design is commonly used for fastening compatible fittings, brackets and other components to timber structures.

Unlike DIN 933 machine bolts, DIN 571 wood screws are designed to engage directly with suitable wood materials rather than standard metric nuts or tapped holes. A correctly sized pilot hole may be required depending on the timber type, screw diameter, edge distance and installation conditions.

A2 (AISI 304) stainless steel provides corrosion resistance for general indoor, outdoor and suitable marine applications. For prolonged saltwater exposure or environments with high chloride concentrations, the suitability of the material should be assessed.

The range includes 16 dimensional configurations across three nominal screw diameters: 6, 8 and 10 mm. Available lengths range from 30 to 100 mm, depending on the selected diameter. Each variant has an individual Osculati part number and is supplied in a cardboard box containing 10 or 25 screws.

Technical Specifications

Brand	Osculati
Product Type	Hexagon Head Wood Screw
Standards	DIN 571 / UNI 704
Material	A2 / AISI 304 Stainless Steel
Head Type	External Hexagonal Head
Drive Type	Hexagon Head for Wrench or Socket
Thread Design	Partially Threaded Wood Screw
Tip Type	Pointed
Intended Material	Suitable Timber and Wood-Based Materials
Available Diameters	6, 8, 10 mm
Available Length Range	30–100 mm
Box Quantities	10, 25 pcs
Packaging	Cardboard Box
Number of Variants	16
Dimensions Format	Nominal Diameter × Screw Length

Features and Applications

Manufactured from A2 (AISI 304) stainless steel.
DIN 571 / UNI 704 hexagon head wood screw design.
External hexagonal head for installation with a matching wrench or socket.
Partially threaded shaft with a smooth section beneath the head.
Pointed tip and wood screw thread for fastening suitable timber components.
Suitable for compatible timber structures, wooden mounting bases, fittings and brackets.
Available in three nominal diameters and 16 dimensional configurations.
Supplied in cardboard boxes containing 10 or 25 screws.

Available Sizes and Part Numbers

Size	Box Quantity	Osculati Part No.
6x30 mm	25 pcs	A2-571-06X030
6x40 mm	25 pcs	A2-571-06X040
6x50 mm	25 pcs	A2-571-06X050
6x60 mm	25 pcs	A2-571-06X060
6x70 mm	10 pcs	A2-571-06X070
8x40 mm	10 pcs	A2-571-08X040
8x50 mm	10 pcs	A2-571-08X050
8x60 mm	10 pcs	A2-571-08X060
8x70 mm	10 pcs	A2-571-08X070
8x80 mm	10 pcs	A2-571-08X080
8x100 mm	10 pcs	A2-571-08X100
10x50 mm	10 pcs	A2-571-10X050
10x60 mm	10 pcs	A2-571-10X060
10x70 mm	10 pcs	A2-571-10X070
10x80 mm	10 pcs	A2-571-10X080
10x100 mm	10 pcs	A2-571-10X100

Size Selection

Select the required nominal screw diameter and length according to the thickness of the components being fastened and the intended timber substrate. Check that sufficient thread engagement is available and that the selected head can be accommodated at the mounting point.

The available lengths vary by diameter. Each dimensional configuration has a fixed box quantity as indicated in the table above.

The exact wrench size, thread pitch, threaded section length and recommended pilot hole dimensions are not specified in the supplied catalogue information.
