The Tecnoseal 00432VLT is a zinc sacrificial propeller anode from the VLT series, designed for compatible marine propeller assemblies. It features a low-profile circular body with three fastening holes arranged around the face and a recessed mounting section on the underside. The anode measures 155 mm (6.10 in) in outside diameter and 30 mm (1.18 in) in overall height, with a mounting diameter (Ø1) of 91 mm (3.58 in), a mounting dimension (i) of 113 mm (4.45 in) and fastening hole diameters (Ø2) of 10.50 mm (0.41 in). Manufactured from zinc and weighing 3.67 kg (8.09 lbs), it provides sacrificial galvanic corrosion protection for electrically connected underwater propeller components.
- Description
- Ask a Question
-
Tecnoseal 00432VLT VLT Zinc Propeller Anode Ø155 mm H30
The Tecnoseal 00432VLT is a zinc sacrificial propeller anode from the VLT series, designed for compatible marine propeller assemblies. It helps protect electrically connected underwater metallic propulsion components against galvanic corrosion by acting as a replaceable sacrificial element.
The anode features a low-profile circular body with three fastening holes positioned around its face and a recessed mounting section underneath. Its outside diameter is 155 mm (6.10 in), and its overall height is 30 mm (1.18 in). The mounting geometry includes a 91 mm diameter (Ø1), a 113 mm dimension (i) and 10.50 mm fastening holes (Ø2). Manufactured from zinc, the anode weighs 3.67 kg (8.09 lbs).
Technical Specifications
Parameter Specification Manufacturer Tecnoseal Product Code 00432VLT Series VLT Product Type Sacrificial propeller anode Material Zinc Body Design Low-profile circular body with recessed mounting section Outside Diameter (Ø) 155 mm (6.10 in) Mounting Diameter (Ø1) 91 mm (3.58 in) Fastening Hole Diameter (Ø2) 10.50 mm (0.41 in) Overall Height (h) 30 mm (1.18 in) Mounting Dimension (i) 113 mm (4.45 in) Weight 3.67 kg (8.09 lbs) EAN 8059617811822
Design and Mounting Configuration
The Tecnoseal 00432VLT has a circular, low-profile design with three mounting holes arranged around the outer portion of the anode. Its recessed underside is intended to accommodate the corresponding mounting area of a compatible VLT propeller assembly.
The manufacturer's technical drawing identifies an outside diameter of 155 mm, a mounting diameter of 91 mm (Ø1), a mounting dimension of 113 mm (i) and 10.50 mm fastening holes (Ø2). The overall height is 30 mm.
Before ordering, compare the anode's outside diameter, mounting recess and fastening hole arrangement with the existing component. These measurements are important when identifying the correct replacement for the intended propeller installation.
Corrosion Protection and Maintenance
Manufactured from zinc, the Tecnoseal 00432VLT functions as a sacrificial component in a compatible marine cathodic protection arrangement. The zinc material is designed to corrode preferentially, helping protect electrically connected underwater metallic propeller components against galvanic corrosion.
Inspect the anode periodically for material consumption and replace it when significantly depleted. During installation, ensure suitable electrical contact between the anode and the metallic component requiring protection.
Scope of Supply
- 1 × Tecnoseal 00432VLT VLT Zinc Propeller Anode Ø155 mm H30
-
