ID
1300733
$ 7,855.04
1-2 weeks delivery time
-
+
The Maxwell VWC 3500 vertical hydraulic windlass (Vetus P105114) is a hydraulic-powered vertical anchor windlass with a 100TDC anti-clockwise (ACW) chainwheel and an integrated warping drum for auxiliary rope handling. Designed for automatic vertical handling of 10–13 mm anchor chain rodes, it offers a maximum pull/lift capacity of approximately 1590 kg and a static holding force of around 2200 kg, engineered for demanding anchoring and docking applications in marine environments.
- Description
- Ask a Question
-
Maxwell VWC 3500 Vertical Hydraulic Windlass 100TDC ACW with Warping Drum
The Maxwell VWC 3500 vertical hydraulic windlass (Vetus P105114) is engineered for automatic vertical handling of chain-only anchor rodes using a hydraulic drive system. Featuring a 100TDC anti-clockwise (ACW) chainwheel and an integrated warping drum, this unit provides controlled anchor retrieval and auxiliary rope handling for docking and mooring operations. Designed with robust marine-grade construction and a durable hydraulic system, it delivers reliable performance for demanding anchoring tasks. :contentReference[oaicite:2]{index=2}
Key Features
- Hydraulic vertical windlass designed for automated handling of chain-only anchor rodes
- 100TDC anti-clockwise (ACW) chainwheel configuration for anchor retrieval
- Integrated warping drum for auxiliary rope hauling and docking support
- Fully automatic single or dual direction chainwheel operation
- High-quality finish on above-deck components, manufactured from marine-grade stainless steel (AISI 316)
- Integral chain pipe and stripper aligned for jam-free chain feed
- Cone-type brake/clutch mechanism for smooth manual free-fall anchoring
- Chainwheel locking pawl for secure anchoring control
- Modular through-deck installation with precise alignment of gearbox and topworks
- Anodized aluminium gearbox and spacer tube for corrosion resistance
- Hydraulic drive system suitable for heavy-duty marine anchoring applications
Technical Specifications
Parameter Value Article Number P105114 Model VWC 3500 Drive Type Hydraulic Chainwheel 100TDC, ACW Rode Type Chain (10–13 mm) Warping Drum Included Maximum Pull / Lift ~1590 kg (3500 lb) Static Holding Force ~2200 kg (4840 lb) Line Speed (Normal Working) ~15 m/min (50 ft/min) Hydraulic Pressure ~138 bar (2000 psi) Hydraulic Flow Requirement ~42 l/min (11 US gal/min) Net Weight (Hydraulic) ~40 kg (88 lb)
Construction and Installation
- Marine-grade stainless steel fasteners and components for enhanced corrosion resistance
- Modular through-deck installation with precise gearbox alignment
- Robust hydraulic and mechanical design suitable for demanding marine environments
-
