ID
1350975
$ 282.66
1-2 weeks delivery time
Type:
- AM28
- AM30*80
- M127 with AM12*22
- AM140
- M160
- AM200
- AM250
- AM400
Shaft Diameter:
- 25
- 30
- 35
- 40
- 45
- 50
- 60
- 70
- 1 3/4"
The Centa Centaflex Clamping Hubs are steel hubs designed for secure shaft connections in Centaflex coupling systems, enabling reliable torque transmission in marine and industrial drivetrain applications. The hubs are available in multiple series including AM28, AM30*80, M127, AM140, M160, AM200, AM250 and AM400, with shaft diameters ranging from 25 mm to 70 mm and 1 3/4" depending on the model. Manufactured by Centa, the hubs are supplied as single pieces and constructed from steel for durability and reliable mechanical performance.
- Description
- Ask a Question
-
Centa Centaflex Clamping Hubs – Shaft Coupling Hubs for Centaflex Couplings (AM28, AM30*80, M127, AM140, M160, AM200, AM250, AM400)
Centaflex Clamping Hubs are mechanical components designed to connect shafts to Centaflex coupling systems. They provide a secure clamping connection that enables reliable torque transmission between drivetrain components in marine and industrial applications.
Manufactured from steel, these hubs are designed for durability and stable performance in demanding environments. Multiple hub series are available to match different Centaflex coupling sizes and shaft diameters.
Key Features
- Clamping hubs for Centaflex coupling systems
- Designed for secure shaft-to-coupling connection
- Manufactured from steel
- Suitable for marine and industrial drivetrain applications
- Available in multiple hub series and shaft diameters
- Supplied as individual units
Available Versions
Hub Type Shaft Diameter Product Number EAN Material AM28 30 mm 94705.030 8720193074245 Steel AM28 35 mm 94705.035 8720193037578 Steel AM28 40 mm 94705.040 8720193037585 Steel AM30*80 25 mm 94713.025 8720193074290 Steel AM30*80 30 mm 94713.030 8720193074306 Steel AM30*80 35 mm 94713.035 8720193074313 Steel AM30*80 40 mm 94713.040 8720193074320 Steel AM30*80 45 mm 94713.045 8720193037592 Steel AM30*80 50 mm 94713.050 8720193037608 Steel M127 with AM12*22 25 mm 94711.025 8720193074269 Steel M127 with AM12*22 30 mm 94711.030 8720193074276 Steel M127 with AM12*22 35 mm 94711.035 8720193074283 Steel AM140 1 3/4" 94740.134 8720193037615 Steel AM140 40 mm 94740.040 8720193074368 Steel AM140 45 mm 94740.045 8720193074375 Steel AM140 50 mm 94740.050 8720193074382 Steel AM140 60 mm 94740.060 8720193074399 Steel M160 25 mm 94702.025 8720193074177 Steel M160 30 mm 94702.030 8720193074184 Steel M160 35 mm 94702.035 8720193074191 Steel M160 40 mm 94702.040 8720193074207 Steel AM200 40 mm 94750.040 8720193037905 Steel AM200 50 mm 94750.050 8720193074412 Steel AM200 60 mm 94750.060 8720193074429 Steel AM200 70 mm 94750.070 8720193037912 Steel AM250 45 mm 94760.045 8720193037936 Steel AM250 60 mm 94760.060 8720193037943 Steel AM250 70 mm 94760.070 8720193037950 Steel AM400 60 mm 94770.060 8720193037974 Steel
Application
- Centaflex coupling systems
- Marine propulsion drivetrain installations
- Industrial shaft coupling systems
- Secure shaft-to-coupling connections
-
