The Flange DN 100 Internal Thread 4" is a galvanised Profec threaded flange combining a DIN flange with a female thread connection. It complies with DIN 2566 PN16, has eight bolt holes, an outside diameter of 220 mm, and a thickness of 20 mm.
- Description
- Ask a Question
-
Flange DN 100 Internal Thread 4"
The Profec threaded flange is galvanised and features a DIN flange with a female thread connection. It complies with DIN 2566 PN16 and is available in various sizes.
- Product code: 86.90.100
- IMPA code: 735780
- Internal thread: 4"
- Bolt holes: 8
- Outside diameter: 220 mm
- Thickness: 20 mm
- Size: DN 100
- Material: Steel
- Pitch circle diameter: 180 mm
-
