ID
1313122
$ 22.29
1-2 weeks delivery time
-
+
The Welding Flange DN 40, Inside Diameter 48.3 mm, 1.1/2" is a standard butt weld flange according to DIN 2576. It features a DIN flange with a butt weld connection, complies with DIN 2576 PN16, has four bolt holes, and an outside diameter of 150 mm.
- Description
- Ask a Question
-
Welding Flange DN 40, Inside Diameter 48,3 mm, 1.1/2"
The weld flange is a standard butt weld flange according to DIN 2576. It features a DIN flange with a butt weld connection and complies with DIN 2576 PN16. Available in various sizes.
- Product code: 86.91.038
- IMPA code: 735556
- Inside diameter: 48,3 mm
- Bolt holes: 4
- Outside diameter: 150 mm
- Size: DN 40
- Material: Steel
- Pitch circle diameter: 110 mm
-
