The Vetus MP34KBW2 Engine Panel (Second Generation, 12 V) features four white-face gauges including a tachometer/hour counter (0–4,000 RPM), voltmeter, water-temperature gauge and oil-pressure gauge; equipped with six monitoring lights, pre-heat/ignition/start switch and built into a splash-resistant IP64 housing; mounting size 255 × 161 mm and built-in depth 121 mm.
- Description
- Ask a Question
-
Vetus MP34KBW2 Engine Panel – 12 V, 4 White Instruments (0–4000 RPM) – Second Generation
The Vetus MP34KBW2 is a high-quality marine engine instrumentation panel from the second generation MP34 series, designed for 12 V systems. It incorporates four white-face analog instruments for essential engine monitoring, along with integrated status indicators and control switch, all housed in a splash-resistant unit suitable for demanding marine environments.
Key Features
- Tachometer with hour counter, measuring 0–4 000 RPM — enables both engine speed monitoring and total running hours tracking.
- Voltmeter for 12 V electrical system monitoring.
- Water temperature gauge to monitor the engine’s cooling system.
- Oil pressure gauge to monitor the lubrication system.
- Six integrated indicator lights to provide status warnings and alerts.
- Ignition/Pre-Heat/Start switch included — key operation for engine start sequence.
- White instrument faces for high visibility and a clean, modern appearance.
- Splash-proof design rated to IP64, suitable for cockpit or flybridge installation in marine settings.
Technical Specifications
Specification Value Model MP34KBW2 (Second Generation) Operating voltage 12 V DC Gauges included Tachometer (0–4000 RPM) with hour counter, voltmeter, water-temperature gauge, oil-pressure gauge Monitoring lights 6 indicator lights Instrument dial colour White Panel front size (W × H) 255 mm × 161 mm Built-in depth 121 mm Ingress protection rating IP64 (splash-resistant) Cabling standard Types A, B & C required
Installation & Compatibility Notes
This engine panel fits the standard MP34 series mounting cut-out (255 × 161 mm). Ensure your system wiring matches the 12 V configuration and that sensor outputs (tachometer sender, temperature sender, oil pressure sender) are compatible with the panel inputs. The white-dial version provides an aesthetic alternative to the standard black-dial units.
Summary
The Vetus MP34KBW2 offers a refined white-dial option within the reputable MP34 series for 12 V marine engine instrumentation. With four critical gauges, six status lights, integrated ignition/start switch and IP64 protection, this panel is a reliable and stylish choice for primary helm stations in vessels requiring compact yet comprehensive monitoring.
-
