The Osculati 27.329.01 LCD Multifunction Instrument is a marine digital dashboard display designed with electronics and interface compatible with Yamaha and Selva outboard motors. The instrument integrates multiple engine monitoring functions including tachometer, speedometer, fuel level, oil pressure, water temperature, voltage, and engine hour counter in a single display. It supports both NMEA 2000 network and analog signals, with four analog inputs (tachometer sensor, fuel level, water temperature, and oil pressure). The unit features a backlit touchscreen LCD with 432×432 resolution, adjustable brightness, and IP67 protection rating. Operating on 9–32V power supply, it supports fuel senders 0–190 Ω or 240–33 Ω, oil pressure 10–185 Ω, and water temperature 301–23 Ω. Installation size is Ø97.5 mm, and the instrument is supplied with 1 m NMEA cable and 1 m analog cable.
- Description
- Ask a Question
-
Osculati 27.329.01 – LCD Multifunction Marine Instrument for Yamaha / Selva Outboards, NMEA 2000 & Analog, Ø97.5 mm
The Osculati 27.329.01 LCD Multifunction Instrument is a marine digital dashboard display designed for use with Yamaha and Selva outboard motors. The unit integrates multiple engine monitoring parameters into a single touchscreen display and supports both NMEA 2000 network communication and analog sensor inputs.
The instrument can display several engine and navigation parameters including tachometer, speed, fuel level, oil pressure, water temperature, engine hours, and voltage. The display features a 432 × 432 pixel LCD touchscreen with adjustable backlighting designed to remain clearly readable even in direct sunlight.
The system supports up to four analog sensor inputs and allows configuration either through NMEA 2000 network data or analog signal sources depending on the installation.
Display Modes
- Mode 1: Speed, COG, Voltage, Fuel Level, Engine Temperature, Oil Pressure, Engine Hours
- Mode 2: RPM, Voltage, Fuel Level, Engine Temperature, Oil Pressure, Engine Hours
Main Functions
- Tachometer
- Speedometer
- Fuel level monitoring
- Oil pressure monitoring
- Water temperature monitoring
- Engine hour counter
- Voltage display
- COG (Course Over Ground)
System Compatibility
- NMEA 2000 network
- Analog sensor signals
- Compatible with Yamaha and Selva outboard motors
- Supports 4 analog inputs: tachometer, fuel level, water temperature, oil pressure
Selectable Sensor Ranges
- Fuel level: 0–190 Ω, 240–33 Ω, or customized
- Oil pressure: 10–185 Ω or customized
- Water temperature: 301–23 Ω or customized
- Speed ratio: 0.5 – 250.0
Alarm Functions
- Fuel level alarm at 10%
- Water temperature alarm at 95°C (203°F)
- Oil pressure alarm at 0.7 bar (10 psi)
- Customizable alarms
Technical Specifications
Product Code 27.329.01 Display Type LCD Touchscreen Resolution 432 × 432 pixels Power Supply 9–32 V Protection Rating IP67 Installation Diameter 97.5 mm Backlight Adjustable backlit display
Supplied With
- 1 m 5-pole NMEA cable with standard connector
- 1 m 6-pole analog cable
-
