ID
1360481
$ 140.60
1-2 weeks delivery time
-
+
The Barton 42335 is a large furling drum with a 95 mm diameter, designed for single-line jib furling systems on dinghies, catamarans, and light cruising yachts. Weighing 290 g, it supports sail areas up to 100 sq ft and delivers a SWL of 554 kg with a break load of 1108 kg.
- Description
- Ask a Question
-
Barton 42335 – Large Furling Drum 95mm, Single Line System, Max Sail 100 sq ft
The Barton 42335 Large Furling Drum is a high-capacity furling solution designed for efficient jib handling on dinghies, catamarans, and light cruising yachts. It enables single-line furling operation, allowing the sail to be deployed and reefed directly from the cockpit.
According to the Barton furler fact sheet :contentReference[oaicite:0]{index=0}, this model features a re-designed drum system with improved line control and enhanced performance, including 3-point line retention and integrated guides that prevent line drop during operation.
The drum is manufactured from glass fibre reinforced nylon for strength and durability, with stainless steel ball races ensuring smooth, low-friction rotation. It is designed to work with the common top swivel (Part No. 42336), forming a complete furling system.
As illustrated in the installation guide :contentReference[oaicite:1]{index=1}, the furling drum is mounted at the bow and connected to the forestay and jib, allowing the sail to be furled by pulling a control line routed back to the cockpit.
Key Features
- Single-line furling drum for jib control
- Suitable for sail areas up to 100 sq ft (9.29 m²)
- 95 mm drum diameter
- Glass fibre reinforced nylon construction
- Stainless steel ball races for smooth rotation
- 3-point line retention system
- Integrated line guides to prevent line drop
- Invisible internal line attachment system
- Multi-position line exit for flexible installation
Technical Specifications
Part Number 42335 Product Type Furling Drum Drum Diameter 95 mm Max Sail Area 100 sq ft (9.29 m²) Safe Working Load (SWL) 554 kg (1221 lbs) Break Load 1108 kg (2242 lbs) Material Glass fibre reinforced nylon + stainless steel bearings Weight 290 g Dimensions 103 × 103 × 86 mm
Applications
- Jib furling systems on dinghies and catamarans
- Dayboats and light cruising yachts
- Single-line furling installations
- Compact and efficient sail handling systems
The Barton large furling drum provides a reliable, durable, and easy-to-install solution for efficient sail control, enhancing both safety and performance on board.
-
