The Barton 42334 is a small furling drum with a 76 mm diameter, designed for single-line jib furling systems on dinghies, dayboats, and light cruising yachts. Weighing 220 g, it supports sail areas up to 60 sq ft and delivers a SWL of 554 kg with a break load of 1108 kg.
- Description
- Ask a Question
-
Barton 42334 – Small Furling Drum 76mm, Single Line System, Max Sail 60 sq ft
The Barton 42334 Small Furling Drum is a compact and efficient furling system designed for jib control on dinghies, catamarans, and light cruising yachts. It enables smooth single-line furling operation, allowing sails to be deployed and reefed directly from the cockpit.
According to the Barton furling system overview :contentReference[oaicite:0]{index=0}, the drum features a re-designed mechanism with improved line control and enhanced performance, including 3-point line retention and integrated guides to prevent line drop during operation.
The drum is manufactured from glass fibre reinforced nylon for strength and durability, with stainless steel ball races ensuring smooth, low-friction rotation. The system works in conjunction with a common top swivel (Part No. 42336) for complete furling functionality.
As shown in the installation guide :contentReference[oaicite:1]{index=1}, the furling drum is mounted at the bow and connected to the forestay and jib, allowing the sail to be furled by pulling a control line routed back to the cockpit.
Key Features
- Single-line furling drum for jib control
- Suitable for sail areas up to 60 sq ft (5.74 m²)
- 76 mm drum diameter
- Glass fibre reinforced nylon construction
- Stainless steel ball races for smooth rotation
- 3-point line retention system
- Integrated line guides to prevent line drop
- Invisible internal line attachment system
- Multi-position line exit for flexible installation
Technical Specifications
Part Number 42334 Product Type Furling Drum Drum Diameter 76 mm Max Sail Area 60 sq ft (5.74 m²) Safe Working Load (SWL) 554 kg (1221 lbs) Break Load 1108 kg (2242 lbs) Material Glass fibre reinforced nylon + stainless steel bearings Weight 220 g Dimensions 84 × 84 × 77 mm
Applications
- Jib furling systems on dinghies and dayboats
- Light cruising yacht sail handling
- Single-line furling installations
- Compact and lightweight rigging setups
The Barton furling drum provides a reliable, lightweight, and easy-to-install solution for efficient sail control, improving safety and convenience during sailing.
-
