The Rule 25SA-6 automatic bilge pump unit provides compact, energy-efficient water removal for small boats and ski-boats using a 12V DC motor. It delivers up to 31 litres per minute (7 gallons per minute) with only 0.8 amps draw, while a built-in thermal cut-off helps protect the motor. Installation and upkeep are simplified by a threaded port and quick-release inlet strainer, and operation is supported by an included check valve to prevent backflow, a vented body to avoid air locking, and a third wire for manual override; it connects to 19 mm (3/4") hose and suits both freshwater and saltwater use.
- Description
- Ask a Question
-
Rule 25SA-6 Automatic Bilge Pump Unit
The Rule 25SA-6 is a compact automatic bilge pump designed to keep small vessels dry by removing bilge water efficiently. Built for tight installations, it combines low power consumption with protective and maintenance-friendly design features for dependable everyday use.
Application
- Water removal in small boats and ski-boats
- Suitable for freshwater and saltwater applications
- Designed for 12V DC electrical systems commonly used on boats and marine vessels
- Fits installations with limited space; can be mounted horizontally or vertically
Compatibility
- For 19 mm (3/4") bore hose connections
- Base is not interchangeable with the old range, but can be mounted on existing screw holes
Technical Specifications
Voltage 12V DC Output Up to 31 litres/min (7 gallons/min) Current Draw 0.8 amps Fuse Size 2 amps Maximum Recommended Discharge Head 2 meters (6.6 feet) Connections 19 mm (3/4") bore hose Dimensions 107 mm high; 64 mm x 74 mm base Actual Weight 0.41 kg (approx. 0.61 kg packed) Packaged Dimensions L: 18.00 x H: 9.00 x W: 17.00 cm Motor Life 1500 hours rated motor life Housing Material Tough, corrosion-resistant plastic body
Product Details
- Automatic operation: Designed to run automatically without a separate float switch
- Manual control option: Third wire enables manual override
- Motor protection: Built-in thermal cut-off helps prevent overheating
- Backflow prevention: Includes a check valve to prevent backflow
- Anti-air-locking design: Vented body helps avoid air locking
- Service-friendly: Quick-release inlet strainer supports rapid cleaning and maintenance
- Installation: Threaded port supports easy installation and maintenance
Features
- Compact design for tight spaces
- Low current draw of 0.8 amps
- Suitable for both fresh and saltwater use
-
