ID
1317193
$ 6,811.24
1-2 weeks delivery time
-
+
The Victor Pumps S83G31T Flange 7,5KW model offers the same dependable performance as the standard S83G31T but includes DN 80 flange connections for both pressure and suction pipes. It handles clean and contaminated liquids with coarse particles and delivers flow rates from 85,000 liters per hour at 10 meters head to 20,000 liters per hour at 35 meters head. The pump operates at 7.5 kW power and 2900 rpm, weighs 94 kg, and has IP68 protection, making it suitable for demanding commercial vessel applications.
- Description
- Ask a Question
-
Victor Pumps S83G31T Flange 7,5KW
This model offers the same reliable deck wash and bilge pump features as the standard S83G31T, but with DN 80 flange connections for pressure and suction pipes.
- Type: S
- Colour: blue
- Pump type: self-priming centrifugal pump
- Impeller type: open impeller
- Motor type: short circuit motor
- Fuse: NOT inbuilt
- Insulation class: IP55
- Shaft seal: SiC on ceramic mechanical seal with Viton, in oil bath
- Material impeller: cast steel
- Material wearing plate: cast steel
- Material pump housing: cast iron
- Material pump shaft: stainless steel
- Liquids handled: clean and contaminated liquids with coarser particles like water, sea water, gas oil, etc.
- Flow rates by head:
- 10 m head: 85,000 litres/hour
- 15 m head: 80,000 litres/hour
- 20 m head: 70,000 litres/hour
- 25 m head: 57,000 litres/hour
- 30 m head: 40,000 litres/hour
- 35 m head: 20,000 litres/hour
- Dimensions (LxWxH): 661 x 327 x 411 mm
- Weight: 94 kg
- Amperage: 13.7 A
- Shaft power: 7.5 kW, 10.0 hp, 2900 rpm
- Product code: 92.09.084
- Suction head: 8.0 m
- Pipe diameter pressure: DN 80 Flange
- Pipe diameter suction: DN 80 Flange
- Pump type: Dry set-up pump, self-priming
- Medium: Water and water with coarse components
- Particle size: 27 mm
- Max discharge head: 38.0 m
- Voltage: 400/690 V
- Current type: AC
- Frequency: 50 Hz
- Protection class: IP68
- ATEX: No
- Separate float switch: Not included
- Free flow: 85,000 L/hour
- Capacity at 5 meter: 85,000 L/hour
-
