ID
1331000
$ 372.01
1-2 weeks delivery time
-
+
The Johnson Pump 32-4000-02 L4000 bilge pump unit is a heavy-duty submersible solution for recreational and commercial marine use, delivering up to 4000 GPH (252 l/min) straight flow on 24V operation. A liquid-cooled 12-pole motor with double ball bearings supports long service life, while the mechanical seal helps prevent shaft wear and simplifies maintenance. Dual hose compatibility with 1-1/2 in (38 mm) and 2 in (50 mm) connections, plus a 1.8 m (6 ft) cable, makes installation practical for demanding bilge applications.
- Description
- Ask a Question
-
Johnson Pump 32-4000-02 L4000 24V Heavy-Duty Bilge Pump
Built for demanding bilge duties, the Johnson Pump 32-4000-02 is a heavy-duty, high-performance submersible bilge pump for both recreational and commercial marine use. It combines robust construction with a liquid-cooled motor design and mechanical sealing to support reliable pumping and service-friendly maintenance.
Application
- Bilge pumping for recreational marine use
- Bilge pumping for commercial marine use
Technical Specifications
Brand Johnson Pump Model L4000 Part Number 32-4000-02 Article Number 6632400002 EAN 8719182073123 Type High-performance, heavy-duty submersible bilge pump Rated Voltage / Current (As Stated) 24 V / 7.5 A Power Consumption 7.5 A Amperage (As Stated) 10 A Fuse 15 A Capacity (Straight Flow) 252 l/min (4000 GPH) Capacity at 1 m Head 166 l/min Performance at 0.9 m Delivery Head (13.6 V / 27 V) 164 l/min (2600 GPH) Performance at 0 m Head (13.6 V / 27 V) 252 l/min (4000 GPH) Maximum Head 7.6 m Hose Connection 1-1/2 in (38 mm) and 2 in (50 mm / 50.8 mm) Dimensions (Max) Diameter 121 mm; Height 216 mm Weight 2.45 kg (5.40 lbs) Shipping Weight 3.80 kg Cable Diameter 2 mm² (14 GA) Cable Length 1.8 m (6 ft) Shaft SS2343 Seal Type Mechanical seal Product Portfolio Submersible bilge pumps
Product Details
- Motor: Liquid-cooled 12-pole motor with double ball bearings
- Seal Design: Mechanical seal to help prevent shaft wear and support maintenance and replacement
- Discharge Ports Included: Threaded straight 38 mm (1-1/2 in) and straight 51 mm (2 in)
- Check Valve: Removable check valve
Features
- Heavy-duty construction for demanding marine bilge service
- High straight-flow capacity up to 252 l/min (4000 GPH)
- Dual large-diameter hose compatibility: 1-1/2 in and 2 in
- Mechanical seal supports durability and easier maintenance
-
