ID
1330846
$ 51.92
1-2 weeks delivery time
-
+
The Johnson Pump 09-1028BT-1 impeller kit is a spline-drive service set for Johnson F7 and F7B pump models, built to support efficient water circulation and cooling. It uses MC97/EPDM construction with an 8-blade impeller, 65 mm outer diameter, 16 mm spline shaft fit, and 80 mm width, and it is supplied with an O-ring, gasket, and glycerine/grease to support service work. This kit is also listed as compatible with SPX F7 pumps and is referenced as a replacement for Johnson 09-1028B, Jabsco 17937-0001 and 920-0001, and Sherwood 18200 impellers.
- Description
- Ask a Question
-
Johnson 09-1028BT-1 Spline-Drive Impeller Service Kit for F7 Pumps
Keep your pump operating smoothly with the Johnson Pump 09-1028BT-1 impeller kit, a service solution for F7-series pump applications. Built around an MC97/EPDM impeller and supplied with key service items, it supports reliable circulation and cooling performance in marine systems.
Application
- Johnson Pump F7 pump model
- Johnson Pump F7B pump models
- Compatible with SPX F7 pumps
Compatibility
Compatible Brands
- Beta Marine
- BMW
- Bukh
- Caterpillar
- Cummins
- Ford
- Isuzu
- John Deere
- Johnson Evinrude
- Kohler
- Kubota
- Lister
- Lombardini
- Mariner
- Mercedes
- Mercruiser
- Mercury
- Mermaid
- Nanni
- Perkins
- Thornycroft
- Vetus
- Volvo
- VM
- Yanmar
Technical Specifications
Brand Johnson Pump Model 09-1028BT-1 Product Portfolio Impeller Outer Diameter 65 mm Inner Diameter / Shaft Diameter 16 mm (spline) Drive Type Spline Drive Width 80 mm Depth 50.2 mm (also listed as 51 mm) Number of Blades 8 Material MC97 (also listed as MC97/EPDM) Insert Material Brass Shipping Weight 0.25 kg Article Number 66091028BT-1 EAN 8719182044925 Reference 12
Product Details
- Kit Type: Impeller kit / service kit (includes O-ring, gasket, glycerine)
- Included Items: Impeller 09-1028BT-1, 1 gasket, 1 grease, 1 O-ring
- Included Seals (listed): Gasket 01-42445, O-ring 0.2172.012
- Impeller Hub: Spline drive
Features
- MC97 impeller designed for cooling duty
- 8-blade design for consistent pumping performance
- Spline-drive fit with 16 mm shaft diameter
- Service kit format supports efficient maintenance with included sealing components and lubricant
Replaces
- Johnson 09-1028B
- Jabsco 17937-0001
- Jabsco 920-0001
- Sherwood 18200 impellers
Alternative To
- Ancor J050009
- Caterpiller 7C3286, 3N1906, 3N 1906
- Cummins 650607
- Deutz 04229640, 04429640, 0442-9640
- Detroit Diesel 5193602
- Mercruiser 47-8013326-01, 47-801332601, 47-8013326-02, 47-801332602
- Oberdorfer 7441
- Perkins 0460024, 24880031, 24880178
- Sherwood 182000
- Solè Diesel 34711008
- Vetus IMP00301
- Volvo 21951356, 3841697, 801277, 825941, 877061-2, 875593-6, 21422632
- Yanmar 127610-42200, 127610-42270, 120650-42310
-
