ID
1332303
$ 44.69
1-2 weeks delivery time
-
+
The Johnson Pump 09-36336-01 cartridge motor unit (motor only) supports reliable pump operation with 12/24 V DC brushless power in a sealed IP67, ball-bearing design suited for continuous duty. Built for water and water/glycol mixtures up to 60% glycol (and freshwater), it handles fluid temperatures from -40°C to +100°C with up to 2.5 bar system pressure, and allows up to 20 minutes of dry running. It includes a universal bracket for flat-surface mounting and provides hose connection options of 25 mm (3/4 in) or 38 mm (1-1/4 in), with a maximum power draw of 315 W and a weight of 3.2 kg.
- Description
- Ask a Question
-
Johnson Pump 09-36336-01 Brushless Cartridge Motor Unit
The Johnson Pump 09-36336-01 is a cartridge motor only, intended as a replacement motor unit for specific Johnson pump applications. With a sealed, brushless DC design, it supports dependable operation in demanding onboard environments and is suitable for continuous duty.
Application
- Johnson Aqua O2 cartridge aerator pump
- Cartridge motor for Aqua Void submersible bilge pump 500 GPH, 12V
Technical Specifications
Model Reference Johnson CM95HP Supply Voltage 12/24 V DC (brushless) Ingress Protection IP67 Duty Rating Suitable for continuous operation Pumped Media Water/glycol mixture (max. 60% glycol), freshwater Liquid Temperature Range Min -40°C, Max +100°C Maximum System Pressure 2.5 bar Hose Connection 25 mm (3/4 in) or 38 mm (1-1/4 in) Maximum Dry-Run Time 20 minutes Maximum Power Consumption 315 W Mounting Universal bracket for flat surfaces (included) Dimensions (L x W x H) 208 mm x 135 mm x 162 mm Weight 3.2 kg
Product Details
- Pump housing: Black anodized aluminum
- Impeller: PA12
- Shaft: Stainless steel
- Motor design: Permanent magnet, ball-bearing
- Scope of supply: Cartridge motor only
Features
- Brushless 12/24 V DC motor supports efficient, low-maintenance operation
- IP67 sealing helps protect the motor in wet marine environments
- Designed for water and water/glycol mixtures up to 60% glycol
- Universal bracket included for flat-surface mounting
-
