ID
1350516
$ 143.45
1-2 weeks delivery time
-
+
The Flojet T5001110 T-Series air-operated diaphragm pump is a compressed-air driven unit rated for 7.6 LPM (free discharge, without back pressure) with automatic shut-off at 5.5 bar (80 PSI). It is self-priming up to 3 m, switches off automatically when the tank/bag is empty, and is specified for a maximum temperature range of 1.1°C to 49°C. Connections are pumped media IN 3/8 inch BP, pumped media OUT 1/4 inch hose, and gas IN 1/4 inch hose; materials include polypropylene, TPE, NBR, and stainless steel, with CE and 1935/2004/EC listed certifications.
- Description
- Ask a Question
-
Flojet T5001110 T-Series Pneumatic Diaphragm Pump
The Flojet T5001110 is a T-Series air-operated diaphragm pump designed for liquid transfer using compressed air. It provides automatic shut-off at its set pressure and can stop automatically when the connected tank or bag is empty.
Technical Specifications
Pump Type Air-operated diaphragm pump Delivery Rate 7.6 L/min (free discharge, without back pressure) Automatic Shut-Off Pressure 5.5 bar (80 PSI) Self-Priming Up to 3 m Temperature Range (Max.) 1.1°C to 49°C Pumped Media Inlet 3/8 inch BP Pumped Media Outlet 1/4 inch hose Gas Inlet 1/4 inch hose Dimensions (H x W x L) 15.70 cm x 13.36 cm x 7.35 cm Materials Polypropylene; TPE; NBR; stainless steel Certifications CE; 1935/2004/EC
Features
- Compressed-air driven diaphragm pumping action
- Automatic shut-off at 5.5 bar (80 PSI)
- Self-priming up to 3 m
- Automatic shut-off when the tank/bag is empty
Product Details
If you are unsure about material compatibility between the pump and the liquid being pumped, confirm compatibility of all wetted materials before putting the pump into operation.
-
