ID
1351246
$ 280.32
1-2 weeks delivery time
-
+
The Aquadrive 6040403 CV15 Adapter Flange Ø100 mm connects Aquadrive CV15 propulsion systems (CVB15.10) to Volvo Penta MS2A, MS2B and MS2L marine gearboxes. Adapter dimensions: D 118 mm, PC/d 80 / 11, Q 4 / 90°, B/M1 60 / 15, Le 30 mm. Supplied as 1 piece.
- Description
- Ask a Question
-
Aquadrive 6040403 – CV15 Adapter Flange Ø100 mm for Volvo Penta MS2A / MS2B / MS2L Gearboxes
The Aquadrive 6040403 Adapter Flange is designed to connect Aquadrive propulsion systems to compatible marine gearboxes. It provides a precise mechanical interface between the gearbox output flange and the Aquadrive constant velocity drivetrain assembly.
This adapter is intended for Aquadrive CV15 propulsion systems (CVB15.10) and is specifically compatible with Volvo Penta MS2A, MS2B, and MS2L marine gearboxes. Precision machining ensures accurate alignment and secure installation within marine propulsion systems.
When used within an Aquadrive drivetrain installation, the adapter flange enables correct integration between the gearbox and the thrust bearing / constant velocity shaft assembly, helping maintain smooth torque transmission and reducing drivetrain stress caused by misalignment.
Key Features
- Adapter flange for Aquadrive CV15 propulsion systems
- Designed for CVB15.10 drivetrain installations
- Compatible with Volvo Penta MS2A, MS2B and MS2L gearboxes
- Ø100 mm gearbox flange interface
- Precision-machined mounting geometry
- Suitable for marine propulsion drivetrain installations
Technical Specifications
Product Name Aquadrive CV15 Adapter Flange Product Number 6040403 CV Size CV15 Flange Diameter Ø100 mm D 118 mm PC/d 80 / 11 Q 4 / 90° B / M1 60 / 15 Le 30 mm Compatible System Aquadrive CVB15.10 Compatible Gearboxes Volvo Penta MS2A, MS2B, MS2L Brand Aquadrive Sales Unit 1 piece -
