The Lowrance 000-16231-001 Eagle 9 without transducer is an IPS-display fishfinder/chartplotter compatible with multiple transducers, featuring worldwide basemap, C-MAP® Discover™ upgrade, 9" screen, 12 V DC operation, and IPX7 waterproof rating, with dimensions 287.2 x 162.5 x 90 mm and 0.9 kg weight.
- Description
- Ask a Question
-
Lowrance 000-16231-001 – Eagle 9 Without Transducer
IPS-display fishfinder/chartplotter with autotuning support and FishReveal compatibility. Designed for use with TripleShot™ HD, SplitShot™ HD, 50/200 and 83/200 HDI transducers. Includes worldwide basemap and C-MAP® DISCOVER™ upgrade option.
Display
Screen size 9" Resolution 1024 x 600 Backlight Pure white LED Brightness 1000 nits Viewing angles 80° top/bottom, 80° left/right
Electrical
Supply voltage 12 V DC (10.8–17 V) Power consumption max 640 mA @ 12 V Typical consumption 640 mA @ 12 V Recommended fuse 3 A
Navigation & Mapping
GPS correction SBAS Time to first fix 45 s Cartography included Worldwide basemap Charts supported C-MAP® DISCOVER™ Waypoints / Routes / Trails 3000 / 100 / 100
Physical
Dimensions (W x H x D) 287.2 x 162.5 x 90 mm Mounting Gimbal bracket or dash mount Weight 0.9 kg Compass safe distance 300 mm
Barcode: 9420064132591
Brand: Lowrance
-
