ID
1341382
$ 1,133.34
1-2 weeks delivery time
-
+
The Lowrance 000-16124-001 Eagle 9 with 50/200 HDI offers CHIRP and DownScan Imaging™ with FishReveal™, autotuning sonar, and a 9" IPS display. It includes worldwide basemap, C-MAP® Discover™ upgrade support, SD card storage, 3000 waypoints, 100 routes, 100 tracks, and is IPX7 rated.
- Description
- Ask a Question
-
Lowrance 000-16124-001 - Fishfinder Eagle 9 With 50/200 HDI
Built to keep fishing simple, this Eagle 9 HDI fishfinder combines Lowrance CHIRP and DownScan Imaging™ with FishReveal™ technology. Autotuning sonar delivers quick setup and optimized performance, while the IPS display ensures clear visibility from all angles. Supplied with a worldwide basemap and upgrade support for C-MAP® Discover™.
Display
Display Size 9 inches Resolution 1024 x 600 Brightness 1000 nits Backlight Color Pure white LED Viewing Angles 80° top/bottom, 80° left/right
Connectivity And Cartography
SD Card Storage 1 slot, microSD® up to 32 GB Charts Supported C-MAP® Discover™ Cartography Included Worldwide basemap chart
Electrical And Environment
Supply Voltage 12v DC (10.8–17VDC) Power Consumption Max 640 mA @ 12 V DC Recommended Fuse Rating 3 A Operating Temperature -15°C to 55°C Storage Temperature -20°C to 60°C Humidity 95% RH at 60°C for 48 hours Waterproof Rating IPX7 (card door closed)
GPS And Physical
GPS Correction SBAS Time To First Fix 45 s Waypoints / Routes / Tracks 3000 / 100 / 100 Dimensions W x H x D 287.2 mm x 162.5 mm x 90 mm Mounting Type Gimbal bracket or dash mount Weight 0.9 kg Interface 8-way keypad, zoom ±, menu, waypoint, power/backlight
Brand: Lowrance
-
