ID
1224506
$ 43.75
1-2 weeks delivery time
-
+
The BEP 701B-PM is a panel-mounted battery master switch designed for On/Off isolation of a single battery bank in 48V DC systems. It is rated at 275A continuous, 455A intermittent (5 min), and 1250A cranking (10 sec), and features 2 × 3/8" (10 mm) studs. Installation uses a standard 2-1/16" (52 mm) panel cut-out, with a compact body depth of 67 mm, and supports cable sizing up to 3/0 AWG (95 mm²) to meet rated performance.
- Description
- Ask a Question
-
BEP 701B-PM - Panel-Mounted Battery Switch On/Off 48V Max. 275A Continuous
The BEP 701B-PM is a compact panel-mounted battery master switch designed for marine electrical systems where a clean dashboard or instrument panel installation is required. It provides dependable On/Off battery isolation for a single battery bank and supports high-current loads in demanding onboard applications.
Key Features
- Panel-mounted battery master switch for compact installations
- On/Off operation for one battery bank
- Designed for standard gauge-style panel cut-out
- Full access for cables inside the rear housing
- Built for marine use with durable plastic construction
Technical Specifications
Part Number 701B-PM Voltage 48V DC Continuous Rating 275A Intermittent Rating (5 min) 455A Cranking Rating (10 sec) 1250A Operation On/Off Stud Size 2 x 3/8" (10 mm) Cable to Meet Rating 3/0 AWG (95 mm²) Panel Cut-Out 2-1/16" (52 mm) Dimensions (L x W x H) 2.75" x 2.75" x 3" (69 x 69 x 67 mm) Product Color Gray Material Plastic EAN 0870216009896 -
