ID
1323341
$ 100.23
1-2 weeks delivery time
-
+
The BEP 184150F-01-1 is a heavy-duty single pole thermal circuit breaker designed for surface mount installation and rated at 150A, 30V DC with a 3000A interrupt capacity. It features a manual reset mechanism with visible trip indication, and is part of the Series 184/185 sealed design for use in engine compartments and bilge areas. Built with a thermoset plastic UL 94V0 housing, it is intended for auxiliary and accessory circuits in trucks, buses, RVs, marine applications, battery chargers, and DC audio systems.
- Description
- Ask a Question
-
BEP 184150F-01-1 - Circuit Breaker HD 150A Manual Reset, Surface Mount (30V DC, 3000A Interrupt)
The BEP 184150F-01-1 is a heavy-duty single pole thermal circuit breaker designed for reliable protection of auxiliary and accessory DC circuits. Rated at 150A and 30V DC, it provides dependable manual reset circuit protection for demanding installations in automotive and marine environments.
Series 184 and 185 circuit breakers are sealed for engine compartment and bilge area applications, making them suitable for harsh operating conditions. The breaker includes a unique manual reset mechanism that also provides a visible indication of a tripped condition, helping with fast troubleshooting and safer operation.
Key Features
- Type: Heavy-duty single pole thermal circuit breaker
- Manual Reset: Yes
- Mounting: Surface mount (F base)
- Visible Trip Indication: Unique reset mechanism indicates tripped condition
- Sealed Design: Series 184/185 suitable for engine compartment and bilge areas
- Hardware & Terminals: Tin plated copper studs, brass rivets, stainless steel locking nuts
- Stud Insulators: Provided on covered units with F (Surface Mount) bases
Applications
- Auxiliary and accessory circuits
- Trucks, buses, and RV electrical systems
- Marine electrical systems
- Battery chargers
- DC audio systems
- Engine compartment and bilge area installations (sealed Series 184/185)
Technical Specifications
Parameter Value Part Number 184150F-01-1 Rated Current 150A Rated Voltage 30V DC Interrupt Capacity 3000A Reset Method Manual Breaker Type Single pole thermal Mounting Type Surface mount Operating Temperature -25°F (-32°C) to 180°F (82°C) Storage Temperature -30°F (-34°C) to 300°F (149°C) Housing Thermoset plastic, UL rated 94V0, 311°F (155°C) Terminal Stud Torque 50 in-lb (5.6 Nm) max. -
