ID
823753
$ 32.01
1-2 weeks delivery time
-
+
The BEP 1001907 is an SPDT lighted toggle switch with an On/Off/On switching function for 12V DC systems. It is rated at 25A at 12V DC and features a red LED indicator for status indication. The switch uses 1/4" blade terminals and is intended for applications requiring illuminated three-position manual control.
- Description
- Ask a Question
-
BEP 1001907 – SPDT Lighted Toggle Switch On/Off/On 12V DC, 25A
The BEP 1001907 is an SPDT (Single Pole Double Throw) toggle switch designed for 12V DC electrical systems. It provides a three-position On/Off/On switching function and includes an integrated red LED for visual indication.
Key Features
- SPDT toggle switch configuration
- On / Off / On switching action
- Designed for 12V DC systems
- Rated at 25A at 12V DC
- Integrated red LED indicator
- Manual toggle operation
Electrical Specifications
Parameter Specification Switch Type SPDT (Single Pole Double Throw) Switch Action On / Off / On Nominal Voltage 12V DC Current Rating 25A at 12V DC LED Red
Connection Details
- Terminal type: 1/4" blade terminals
Typical Applications
The BEP 1001907 toggle switch is suitable for marine and industrial electrical installations where illuminated three-position switching is required, such as lighting circuits, auxiliary power control, and directional or mode selection circuits.
-
