Vetus BOA007A is a large rectangular bolt-on aluminium hull anode designed for high-capacity cathodic protection in freshwater, brackish water, and saltwater environments. With an overall length of 450 mm, an approximate center-to-center distance of 410 mm, and a net weight of about 3.70–4.50 kg, this anode is intended for extended protection of large underwater metal surfaces on commercial and heavy-duty vessels.
- Description
- Ask a Question
-
Vetus BOA007A Bolt-On Aluminium Hull Anode Rectangular 4.50 kg
The Vetus BOA007A is a high-capacity aluminium hull anode developed for effective cathodic protection of large underwater metal components in freshwater, brackish water, and saltwater environments. Manufactured from aluminium alloy in accordance with MIL-A-24779 (SH) standards, this anode provides high electrochemical efficiency and reliable corrosion prevention for hull structures, rudders, steering systems, and other heavily exposed metal parts.
Aluminium anodes are a lightweight and environmentally considerate alternative to zinc and provide superior performance in brackish water and areas with lower salt concentrations. The BOA007A combines very large mass with an extended rectangular profile, enabling wide protection coverage and long service intervals. It is suitable for bolt-on installation and can be adapted for weld-on or custom-drilled mounting where required.
Key Features
- Large aluminium hull anode for extended protection coverage
- Suitable for freshwater, brackish water, and saltwater use
- Manufactured to MIL-A-24779 (SH) specification
- Rectangular streamlined contour
- Bolt-on mounting, adaptable for custom installations
- Lightweight and environmentally considerate material
Technical Specifications
Parameter Value Product Code BOA007A Anode Material Aluminium alloy (MIL-A-24779 SH) Anode Type Bolt-on hull anode Contour Rectangular Overall Length 450 mm Center-to-Center Distance Approx. 410 mm Net Weight 3.70–4.50 kg
Application Parameters
- Cathodic protection of large underwater metal components
- Use on vessels operating in freshwater, brackish water, and saltwater
- Protection of hulls and major structural metal parts
- Suitable for commercial and heavy-duty marine applications
- Recommended inspection annually and replacement at 50% wear
-
