ID
1382938
$ 1,406.92
1-2 weeks delivery time
Diameter, mm:
- 6
- 8
- 10
Length, m:
- 30
- 50
The Plastimo 316L Stainless Steel Calibrated Anchor Chain is manufactured from AISI 316L stainless steel for excellent corrosion resistance in marine environments. Produced to DIN 766A and ISO 261016 standards, the calibrated chain is designed for anchor windlasses, with regular links compatible with most gypsies. Available in 6 mm, 8 mm and 10 mm diameters and supplied in 30 m or 50 m drums depending on the selected variant, the chain provides safe working loads from 1,000 kg to 1,250 kg and breaking loads from 4,030 kg to 5,096 kg.
- Description
- Ask a Question
-
Plastimo 316L Stainless Steel Calibrated Anchor Chain DIN 766A – 6-10 mm, 30-50 m
The Plastimo 316L Stainless Steel Calibrated Chain is designed for reliable anchoring systems requiring excellent corrosion resistance and precise compatibility with anchor windlasses. Manufactured from premium AISI 316L stainless steel, the chain delivers long service life in demanding marine environments.
Produced to DIN 766A and ISO 261016 standards, the calibrated link dimensions ensure compatibility with most anchor windlass gypsies. The chain is supplied in drums and is available in several diameters and lengths for a wide range of marine anchoring applications.
Key Features
- Manufactured from AISI 316L stainless steel
- Calibrated anchor chain
- Suitable for anchor windlasses
- Manufactured to DIN 766A and ISO 261016 standards
- Regular links compatible with most windlass gypsies
- Excellent corrosion resistance in marine environments
- Supplied in plastic drums
Available Variants
Part Number Diameter Length Total Weight Safe Working Load Breaking Load 57176 6 mm 50 m - - - 57177 8 mm 30 m 42 kg 1,000 kg 4,030 kg 57178 10 mm 30 m 69 kg 1,250 kg 5,096 kg
Technical Specifications
Brand Plastimo Product Type Calibrated Anchor Chain Material AISI 316L Stainless Steel Standards DIN 766A / ISO 261016 Windlass Compatibility Suitable for anchor windlasses Diameter Range 6-10 mm Length Options 30 m or 50 m Safe Working Load Up to 1,250 kg (depending on variant) Breaking Load Up to 5,096 kg (depending on variant) Packaging Plastic Drum Applications Marine anchoring and anchor windlass systems -
