ID
1282211
$ 241.59
1-2 weeks delivery time
-
+
The Maxwell 24V Reversing Solenoid Dual Relay for RC8-8, RC10, RC12, 1000–3500 Series (Vetus SP5105) is a heavy-duty dual-direction solenoid designed for 24 V DC marine windlass systems. Used in conjunction with remote Up/Down panels, AutoAnchor™ rode counters, handheld remotes, or foot switches, it provides reliable motor direction control for compatible Maxwell windlasses in demanding marine environments.
- Description
- Ask a Question
-
Maxwell 24V Reversing Solenoid Dual Relay for RC8-8, RC10, RC12, 1000–3500 Series (Vetus SP5105)
Specification Details Article Number Vetus SP5105 Product Type Reversing solenoid Relay Configuration Dual relay Operating Voltage 24 V DC Motor Control Dual-direction (Up / Down) Compatible Windlass Series RC8-8, RC10, RC12, 1000 Series, 3500 Series Motor Types Supported Permanent magnet (2 terminal), series wound (3 terminal), field wound (4 terminal) Enclosure Rating IP66 Ignition Protection Ignition protected Installation Recommendation Install in a dry area
Technical Features
- Heavy-duty reversing solenoid for 24 V DC marine windlass systems
- Dual-relay design enables reliable Up/Down motor direction switching
- Compatible with multiple motor types including permanent magnet, series wound, and field wound motors
- IP66-rated enclosure provides protection against dust and water ingress
- Ignition-protected design suitable for marine installations
- Designed to operate with remote control panels, foot switches, handheld remotes, and rode counters
Applications
- Reversing control of anchor windlass motors on 24 V DC systems
- Integration with remote Up/Down windlass control interfaces
- Marine anchoring systems requiring durable and reliable dual-direction motor control
Benefits
- Durable construction suitable for harsh marine environments
- Versatile compatibility across a wide range of Maxwell windlass models
- Compact design allowing straightforward integration without compromising performance
-
