The Maxwell 3500 VWCLP hydraulic vertical anchor windlass, anticlockwise (ACW) (Vetus P105141), is a heavy-duty marine anchoring system with hydraulic drive and a 200 TDC working load capacity for automatic chain-only anchor handling. Built for demanding marine environments, this vertical windlass is compatible with standard 10–13 mm anchor chainwheel sizes and engineered to provide smooth, reliable anchoring performance under load.
- Description
- Ask a Question
-
Maxwell 3500 VWCLP Hydraulic Vertical Anchor Windlass, ACW, 200TDC (Vetus P105141)
The Maxwell 3500 VWCLP Hydraulic Vertical Anchor Windlass with anticlockwise (ACW) rotation is engineered for robust and reliable automatic anchor chain handling on marine vessels. Featuring a hydraulic drive and rugged construction suitable for harsh marine conditions, this vertical windlass is designed for chain-only operation with a working load capacity of 200 TDC and compatibility with standard marine chain sizes.
Key Features
- Hydraulic powered vertical windlass for automatic chain-only anchor handling
- Anticlockwise (ACW) chainwheel configuration for controlled anchor operation
- Designed for demanding marine environments with durable construction
- Compatible with 10 mm–13 mm marine chain sizes
- Winch-only configuration (without reel) for versatile installations
Hydraulic Specifications
Parameter Specification Drive Type Hydraulic Hydraulic Flow Requirement Approx. 42 L/min (standard 3500 series) :contentReference[oaicite:1]{index=1} Hydraulic Pressure Approx. 138 bar (typical) :contentReference[oaicite:2]{index=2}
Mechanical Specifications
Specification Value Model 3500 VWCLP Working Load Capacity (TDC) 200 Rotation Direction ACW (Anticlockwise) Compatible Chain Size 10 mm – 13 mm (3/8″ – 1/2″) :contentReference[oaicite:3]{index=3} Sprocket Standard 3182/XXX chainwheel (typical) :contentReference[oaicite:4]{index=4}
Performance and Usage
- Efficient automatic anchor chain retrieval and deployment
- Hydraulic drive provides smooth and powerful operation
- Suitable for medium to large yachts and workboats
- Reliable anchoring performance in varied marine conditions
Installation and Operation Notes
- Designed for vertical through-deck installation with adequate deck reinforcement
- Hydraulic supply system must meet specified flow and pressure requirements
- Select and install correct chainwheel sprocket to match actual chain diameter
- Regular maintenance recommended to ensure long-term reliable operation
-
