ID
1282105
$ 4,584.53
1-2 weeks delivery time
-
+
The Maxwell VW 1500 hydraulic anchor windlass with drum (article Vetus P102783) is a vertical hydraulic drive windlass with a 150TDC chain/rope configuration designed for traditional rope and chain anchor rodes where manual transfer to the chainwheel is required. It supports 6–10 mm chain size, provides robust pull capacity up to approximately 850 kg, features an integrated warping drum, and is suitable for sailing and motor vessels needing reliable anchoring performance with hydraulic power.
- Description
- Ask a Question
-
Maxwell VW 1500 Vertical Hydraulic Anchor Windlass with Drum 150TDC (Vetus P102783)
The Maxwell VW 1500 hydraulic anchor windlass with integral drum is engineered for dependable and powerful anchoring on marine vessels requiring hydraulic power systems. Designed for traditional rope and chain combination anchor rodes, operation involves manual transfer of the rode from the warping drum to the chainwheel. Its vertical configuration and modular construction support installation in confined anchor locker spaces, with the option for horizontal bulkhead mounting as needed.
Design and Functional Features
- Designed for traditional rope and chain anchor systems with manual transfer to the chainwheel
- Integrated MAX-grip™ snag-free warping drum allowing rope hauling from any direction
- Chainwheel clutch disengagement for precise control of rope and chain
- Capability to operate two anchors from a single windlass unit
- Supports standard shackle and thimble rope-to-chain connections
- Vertical layout suitable for compact anchor locker installations
Construction and Materials
- Above-deck components manufactured from marine-grade stainless steel (AISI 316) and chromed bronze
- Anodized aluminium gearbox and spacer providing enhanced corrosion resistance
- Hydraulic drive system optimized for marine anchoring applications
- Marine-grade stainless steel fasteners for secure alignment and long-lasting durability
Brake and Control System
- Cone-type brake and clutch mechanism enabling manual free-fall anchoring
- Smooth progressive clutch engagement for controlled operation
- Chainwheel locking pawl for secure anchoring control
Installation and Maintenance
- Modular design simplifies through-deck installation
- Allows horizontal mounting on fore-and-aft bulkheads inside the chain locker
- Easily disassembled construction for servicing and maintenance
Technical Specifications
Parameter Specification Drive Type Hydraulic Configuration Vertical Rode Type Rope / Chain Warping Drum Yes Chain Sprocket 150TDC Supported Chain Size 6 – 10 mm Maximum Pull / Lift Up to approx. 850 kg Hydraulic Pressure 138 bar (typical series) Hydraulic Flow 20 l/min (typical series) -
