MZ ELECTRONIC Universal Anchor Windlass Control Panel with LCD Chain Counter

ID 675932

$ 547.26

1-2 weeks delivery time

Type:

Wired connection
Radio connection

The MZ ELECTRONIC Universal Anchor Windlass Control Panel combines advanced windlass control with an integrated LCD chain counter and backlit buttons for clear operation in all lighting conditions. Compatible with 12V and 24V systems, it is available in both wired and radio versions and supports an optional magnetic sensor for chain measurement. With an IP65 protection rating and a maximum measurable chain length of 999 metres, the display provides real-time information including chain length, chain speed, supply voltage, motor current, docking alarm and windlass operating hours. The panel measures 100 × 100 × 32 mm.

Description
Ask a Question

MZ ELECTRONIC Universal Anchor Windlass Control Panel with LCD Chain Counter – Wired & Radio Versions, 12/24V

The MZ ELECTRONIC Universal Anchor Windlass Control Panel is designed to provide comprehensive monitoring and control of electric anchor windlass systems. Featuring an LCD display with backlit buttons, the panel delivers clear operating information while allowing convenient control of the windlass.

The display provides real-time information including chain length hauled in or paid out, chain speed, supply voltage, motor current draw, docking alarm status and total windlass operating hours. The system supports a maximum measurable chain length of 999 metres.

Available in both wired and radio versions, the control panel is compatible with 12V and 24V electrical systems. An optional magnetic sensor (02.355.00) can be added when required for chain counting functionality. The IP65-rated housing is suitable for marine installations.

Key Features

Universal control panel for electric anchor windlasses;
LCD display with backlit buttons;
Displays chain length hauled in or paid out;
Chain speed indication;
Supply voltage display;
Motor current draw indication;
Docking alarm indication;
Windlass operating hours display;
Maximum measurable chain length: 999 m;
Available in wired and radio versions;
Optional magnetic sensor available;
IP65 protection rating.

Technical Specifications

Application	Electric anchor windlass control and chain counting
Operating Voltage	12 / 24 V
Display	LCD with backlit buttons
Protection Rating	IP65
Maximum Chain Length	999 m
Optional Accessory	Magnetic sensor 02.355.00 (if required)
Dimensions	100 × 100 × 32 mm
