Lofrans Titan B Windlass 24V for Boats 18-24m, Chain 13 mm

SKU: CN AB428938 / ALP 71232

$ 13.059,60

1-2 weeks delivery time

- +

Add to cart

The Lofrans Titan B 2300W/24V Windlass is engineered for yachts and motorboats 18–24 m (65–85 ft). Built with a marine anodized aluminum body and IP66-rated motor, it delivers 2700 kg maximum pull and a lifting capacity of 1500 kg. Compatible with 10 mm and 13 mm DIN766 chains, the Titan B ensures reliable anchoring with independent drum operation, manual override, and heavy-duty performance.

Description
Ask a Question

Lofrans Titan B 2300W/24V Horizontal Windlass – For Boats 18–24 m

The Lofrans Titan B Windlass is a heavy-duty horizontal anchor winch designed for large vessels from 18 to 24 meters (65–85 ft). With a 2300W 24V motor, it delivers powerful anchoring performance with a maximum pull of 2700 kg and a lifting load capacity of 1500 kg. Constructed from marine-grade anodized aluminum, it is built to withstand harsh marine environments while ensuring long-lasting reliability.

Main Features

Heavy-Duty Motor: 2300W / 24V motor designed for large yachts and commercial vessels.
Exceptional Power: Max pull of 2700 kg and lifting load up to 1500 kg.
Durable Construction: Marine anodized aluminum body with optional white polyester coating.
Independent Gypsy and Drum: Flexible operation for chain and rope handling.
IP66 Protection: Electric motor designed for continuous operation in demanding marine conditions.
Chain Compatibility: Available for 10 mm and 13 mm DIN766 chains.
Manual Safety Features: Includes manual chain release and manual override.

Technical Specifications – Lofrans Titan B

Voltage (V)	Power (W)	Boat Length (m)	Chain Size (mm)	Max Pull (kg)	Lifting Load (kg)	Line Speed (m/min)
24	2300	18–24	10 mm DIN766	2700	1500	10–16
24	2300	18–24	13 mm DIN766	2700	1500	10–16

The Lofrans Titan B Windlass is the perfect solution for larger vessels that require strength, reliability, and advanced anchoring capabilities. With its robust construction and powerful performance, it remains a trusted choice for yachts and motorboats worldwide.
