The Jabsco 14609-0001B neoprene impeller is a standard 6-blade water pump impeller for marine and industrial use, built with a single flat drive hub and an 8 mm shaft size. Its 32 x 12 mm dimensions and approx. 4°C to 80°C operating temperature range support dependable pumping of water and other simple fluids, with a brass insert and high-pressure suitability noted for demanding applications.
- Description
- Ask a Question
-
Jabsco 14609-0001B Neoprene Water Pump Impeller Unit
The Jabsco 14609-0001B is a standard neoprene impeller designed for water pumping in both marine and industrial systems. With a 6-blade design and single flat drive hub, it supports efficient fluid transfer for water and other simple fluids. As with any pump component, material compatibility should be confirmed for the pumped medium before operation.
Application
- Marine systems
- Industrial systems
- Pumping simple media such as water
Technical Specifications
Brand Jabsco Product Type Impeller Supplier Code 14609-0001B Order Number 00320219 Barcode 671880571128 Diameter 32 mm Depth 12 mm Shaft Diameter 8 mm Number of Blades 6 Drive Type Single Flat Drive Material Neoprene Insert Material Brass Operating Temperature Range Approx. 4 C to 80 C Pressure Range High Shipping Weight 0.06 kg Marking 005 HP NE 1FL
Product Details
- Construction: Neoprene impeller with brass insert
- Design: 6-blade impeller for standard water pump service
- Fit Information: 32 x 12 mm size with 8 mm shaft specification
Features
- Standard neoprene impeller for general water pumping
- Single flat drive hub for secure torque transfer
- Designed for marine and industrial pumping of water and other simple fluids
- Approx. 4 C to 80 C operating temperature range
-
