ID
1345663
$ 3,682.21
1-2 weeks delivery time
-
+
The FP-3B 20x14 LH bladeset features a 20-inch diameter, 14-inch pitch, 3 blades, 100 mm hub length, left-hand rotation, and a developed area ratio of 92, made from Nickel Aluminum Bronze and fits a 40 mm shaft, suitable for product 735007.
- Description
- Ask a Question
-
Flexofold Bladeset FP-3B 20x14 LH
This 20-inch diameter bladeset with a 14-inch pitch is designed for left-hand rotation and fits a 40 mm shaft diameter. Manufactured from Nickel Aluminum Bronze, it includes 3 blades and a 100 mm hub length. The Developed Area Ratio (DAR) is 92. Suitable for product 735007.
Product Highlights
- Rotation Direction: Turning Left
- Material: Nickel Aluminum Bronze (Ni.Al.Br.)
- Number of Blades: 3
- Hub Length: 100 mm
- Taper: 1 : 10
- Max Shaft Hole Diameter: 40 mm
Technical Data
Article Code: SP7872014 Sales Unit: 1 piece Developed Area Ratio (DAR) %: 92 Shaft Diameter (mm): 40 Product Diameter (inch): 20" Product Diameter (mm): 508 Pitch (inch): 17"
Brand: Flexofold (Article code: SP7872014)
-
