ID
1252072
$ 1,803.98
1-2 weeks delivery time
Voltage:
- 12V
- 24V
- 48V
Power, W
- 3000
- 5000
- 8000
- 10000
- 15000
Current (Amps):
- 32
- 35
- 70
- 110
- 120
- 140
- 200
- 220
The Victron MultiPlus-II series offers a full range of powerful inverter/chargers from 3000 VA to 15000 VA with 12V, 24V, and 48V battery support. Each unit combines a pure sine wave inverter, an advanced adaptive charger, a fast AC transfer switch, and powerful ESS capabilities. With integrated VE.Bus communication, PowerControl and PowerAssist, built-in anti-islanding, and support for parallel and three-phase operation, the MultiPlus-II is ideal for marine, mobile, and grid-connected energy storage systems.
- Description
- Ask a Question
-
Victron Energy MultiPlus-II Inverter/Charger Series is a comprehensive line of advanced inverter/chargers designed for professional marine, RV, off-grid, and energy storage system (ESS) applications. The MultiPlus-II combines all the features of the original MultiPlus and MultiGrid in a single device and introduces compatibility with dynamic ESS, anti-islanding protection, and external current sensing.
Main Features:
- Integrated Inverter/Charger – pure sine wave output, adaptive battery charging, and ultra-fast AC transfer switch.
- PowerAssist – boosts limited shore or generator input by supplementing with battery power.
- ESS Support – enables full integration into grid-connected storage systems with solar and live-pricing responsiveness.
- Anti-Islanding – compliant with a growing list of country-specific grid codes and certifications.
- Dual AC Output – critical loads stay powered even when the grid is down.
- Remote Monitoring & Configuration – via Cerbo GX, VRM Portal, VictronConnect, or MK3-USB interface.
- Scalable Architecture – supports parallel and three-phase operation for large systems (up to 75 kW).
Model Overview:
Model Battery Voltage Cont. Power (W) Apparent Power (VA) Charger Current (A) Transfer Switch Dimensions (mm) Weight PMP122305010 12 V 2400 W 3000 VA 120 A 32 A 546 × 275 × 147 19 kg PMP122505010 12 V 4000 W 5000 VA 220 A 50 A 702 × 345 × 152 33 kg PMP242305010 24 V 2400 W 3000 VA 70 A 32 A 499 × 268 × 141 30 kg PMP242505010 24 V 4000 W 5000 VA 120 A 50 A 607 × 330 × 149 30 kg PMP482305010 48 V 2400 W 3000 VA 35 A 32 A 499 × 268 × 141 30 kg PMP482505010 48 V 4000 W 5000 VA 70 A 50 A 565 × 320 × 149 30 kg PMP482805000 48 V 6400 W 8000 VA 110 A 100 A 642 × 363 × 206 42 kg PMP483105000 48 V 8000 W 10000 VA 140 A 100 A 677 × 363 × 206 49 kg PMP483150000 48 V 12000 W 15000 VA 200 A 100 A 810 × 405 × 217 80 kg
Advanced System Capabilities:
- Battery voltage ranges: 12V (9.5–17 V), 24V (19–33 V), 48V (38–66 V)
- AC input voltage: 187–265 VAC, frequency: 45–65 Hz
- Peak power up to 27,000 W on 48V/15000 model
- Programmable relay for alarms, automation, or generator start/stop
- Compatible with lithium, AGM, GEL, and lead-acid batteries
- Operating temperature: -40 to +65°C (fan cooled)
Whether you're building a resilient off-grid system, upgrading marine power electronics, or creating a flexible hybrid ESS, the Victron MultiPlus-II series provides unmatched reliability, expandability, and control.
Manufacturer: Victron Energy, The Netherlands
Documents
Victron Energy MultiPlus-II Inverter:Charger Size: 576,9 KbVictron ESS Manual Size: 1,2 MbVictron Multiplus II Manual Size: 7,7 Mb -
