Cristec YPO45-24-30/MPPT is a compact MPPT solar controller providing efficient and silent charging at up to 30 A, with automatic voltage selection, advanced charge control, and remote monitoring through CAN-Bus.
- Description
- Ask a Question
-
Cristec YPO45-24-30/MPPT - Mpptpower+ 45V 24V 30A Solar Controller
The Cristec MPPTPOWER+ solar controller is engineered to optimize battery charging from solar panels using advanced MPPT technology. Compact, robust, and completely silent, it integrates easily into onboard, mobile, or autonomous energy systems. Intelligent charge management with a 5-step charging curve maximizes efficiency and extends battery service life, while CAN-BUS communication enables remote supervision.
Key Features
- High-efficiency MPPT solar regulation
- Automatic output voltage selection for 12V and 24V systems
- Passive cooling with fanless, silent operation
- Reliable and intelligent battery charge management
- Remote monitoring via CAN-BUS interface
Technical Data
Regulator Type MPPT Input Voltage 10–80 VDC Tension 10–45 V Output Voltage 12/24 VDC (automatic) Intensity 30 A Max Power 800 W Cooling Passive (fanless) Battery Types Lead, AGM, Gel, Lithium (LiFePO4) Length 238 mm Height 220 mm Depth 81 mm Weight 2 kg
Brand: Cristec
Article Code: YPO45-24-30/MPPT -
