ID
1360656
$ 43.57
1-2 weeks delivery time
-
+
The Barton N01310 is a Size 1 triple fixed eye block with three 30 mm plain bearing sheaves, designed for ropes up to 8 mm. Weighing 89 g, it provides reliable load handling with a working load of 355 kg and break load of 710 kg, making it ideal for multi-purchase systems requiring stable mounting.
- Description
- Ask a Question
-
Barton N01310 - Triple Fixed Eye Block Size 1 30mm – Plain Bearing, 3x Ø30mm Sheaves, Max Rope 8mm
The Barton N01310 Triple Fixed Eye Block is part of the Size 1 (30 mm) range, featuring three plain bearing sheaves and an internal steel frame for enhanced strength and durability. This configuration enables higher mechanical advantage in compact multi-purchase systems.
The fixed eye attachment ensures secure and stable mounting, while the plain bearing system is optimized for high load capacity and controlled adjustment. This block is suitable for dinghies, dayboats, and a wide range of sailing applications requiring dependable performance :contentReference[oaicite:0]{index=0}.
Key Features
- Triple sheave block for multi-purchase systems
- Internal steel frame for increased strength and durability
- Plain bearing system for high load applications
- Fixed eye for secure mounting
- Robust construction – 89 g
Technical Specifications
Part Number N01310 Block Type Triple Fixed Eye Size Size 1 (30 mm) Sheave Diameter 3 × 30 mm x 12 mm (1 3/16"" x 15/32"") Bearing Type Plain Bearing Number of Sheaves Triple Max Rope Diameter 8 mm (5/16"") Safe Working Load (SWL) 355 kg (782 lbs) Break Load 710 kg (1565 lbs) Weight 89 g Dimensions 57 × 56 × 32 mm
Applications
- Multi-purchase systems
- Control and trimming systems
- Fixed rigging installations
- Dinghies and small to medium sailing boats
The Barton Size 1 plain bearing triple fixed eye blocks are engineered for strength, durability, and efficient load handling, delivering reliable performance in compact sailing systems.
-
