The Barton 60360 is a flush-mounted deck plate with M8 fixing eye, manufactured from solid 316 stainless steel with a polished finish. Featuring a 50 mm diameter base, sealed internal thread, and 2000 kg safe working load, it provides a strong, low-profile anchoring solution with a blanking plug to prevent water ingress when not in use.
- Description
- Ask a Question
-
Barton 60360 – Flush Deck Plate with Eye M8, Ø50mm, Spigot Ø17mm, SWL 2000kg, 316 Stainless Steel
The Barton 60360 Flush Deck Plate with Fixing Eye is a high-strength anchoring point designed for flush installation on deck surfaces. Precision-machined from solid 316 stainless steel with a highly polished finish, it delivers excellent corrosion resistance and long-term durability in harsh marine environments.
Featuring a central M8 threaded fixing eye, the unit is supplied with a stainless steel blanking plug that seals the internal thread when not in use, preventing water ingress and eliminating deck obstructions. The flush-mounted design minimises trip hazards while maintaining a clean deck profile. :contentReference[oaicite:0]{index=0}
Key Features
- Flush-mounted deck plate with integrated M8 fixing eye
- Manufactured from solid 316 stainless steel
- Highly polished finish for corrosion resistance
- Supplied with stainless steel blanking plug
- Sealed internal thread prevents water ingress
- Low-profile design reduces trip hazards
- Suitable for high-load applications up to 2000 kg SWL
Technical Specifications
Part Number 60360 Product Type Flush Deck Plate with Fixing Eye Thread Size M8 Base Diameter 50 mm (1.97") Spigot Diameter 17 mm Depth 22 mm (0.87") Safe Working Load (SWL) 2000 kg (4100 lbs) Material 316 stainless steel Weight 160 g Dimensions 90 × 50 × 30 mm
Applications
- Temporary fixing eyes and tie-down points
- Deck-mounted boarding ladders
- Stand-up blocks and rigging attachments
- Davit and lifting point installations
- Life raft and dive tank securing systems
The Barton flush deck plate range provides a strong, versatile, and discreet anchoring solution, combining safety, durability, and clean deck integration for a wide range of marine applications.
-
