ID
1259008
$ 440.86
1-2 weeks delivery time
-
+
The Rule 3800 livewell/washdown centrifugal pump is a 12V DC unit rated for 220 liters per minute (48 gallons per minute) and intended for below-waterline installation with a flooded inlet. It is non-self-priming, uses 38 mm (1-1/2 inch) inlet/outlet ports, and is designed for quiet operation in a durable plastic body with a maximum recommended delivery head of 3 meters.
- Description
- Ask a Question
-
Rule 3800 Marine Livewell and Washdown Pump
The Rule 17A is a marine centrifugal pump designed for high flow at low head for applications such as livewell circulation and low-pressure washdown. It is a non-self-priming pump that must be installed below the waterline (submerged / flooded inlet) for proper operation.
Technical Specifications
Supplier Code 17A Order Number 00304465 Barcode 042237083388 Pump Type Centrifugal Voltage 12 VDC Flow Rate 220 liters per minute (48 gallons per minute) Maximum Recommended Delivery Head 3 meters Priming Non-self-priming; requires flooded inlet Installation Below waterline; requires submersion for proper function Inlet / Outlet Size 1-1/2 inch (38 mm) Body Material Plastic Dimensions (H x W x D) 165 x 210 x 165 mm Dimensions (L x W x H) 210 x 165 x 165 mm Power Consumption 15.5 Ah Maximum Power Consumption 8 Amps Fuse Size 25 Amp Weight 2.89 kg (approx. 3.39 kg packed) Motor Life Rated for 2,500 hours Duty Rating Continuous duty
Features
- High flow, low head performance for water circulation and washdown tasks
- Quiet operation for marine installations
- Durable plastic housing for long-lasting service
Compatibility
- For 38 mm (1-1/2 inch) bore hoses
- Works with Rule Float Switches for automatic operation
-
