Linak DL12 compact lifting column for indoor electric adjustment systems, suitable for applications such as flatscreen positioning and parallel installations. The three-section telescopic column features a 60 x 100 mm rectangular profile, 660 mm stroke, 700 N force and integrated PIEZO™ technology. Product 036405 operates on 12V.
- Description
- Ask a Question
-
Linak 036405 - DL12 Compact Lifting Column 12V
The Linak DL12 is a compact three-section telescopic lifting column designed for indoor electric adjustment applications. Its compact rectangular profile and long stroke make it suitable for installations where controlled vertical movement is required, including flatscreen adjustment systems.
The DL12 is also suitable for parallel applications. Its three-section construction provides a 660 mm stroke while maintaining a compact installation size. Integrated PIEZO™ sensor technology helps minimize the risk of damage if an obstacle is encountered during movement.
Features
- Compact three-section telescopic lifting column
- Suitable for indoor applications
- Suitable for flatscreen adjustment systems
- Suitable for parallel applications
- Rectangular profile: 60 x 100 mm
- Integrated PIEZO™ technology
- Designed for quiet operation
Technical Specifications
Product Number 036405 Brand Linak Series DL12 Voltage 12 V Stroke Length 660 mm Installation Size 518 mm Profile 60 x 100 mm Force 700 N Bending Moment Up to 150 Nm Speed 38 mm/s Technology PIEZO™ -
